EC603e2 Solid Electrolyte Electrochemical Cell | ||||
Product code | Product Image | Product Features | Common Features | Product description |
| 28012306-1 |  | As shown in the figure, the solid-state electrolytic cell adopts a sandwich structure as a whole, builds a gas-solid interface, uses a solid electrolyte to replace the electrolyte, avoids the introduction of anions/cations, and directly realizes the preparation of high-purity liquid product aqueous solutions. | The specific structure is as follows: 1. Cells 1 and 3 are bipolar plates with serpentine airflow channels on the inside, which can effectively increase the concentration of gas reactants on the catalyst surface to achieve high current density. 2. The double-layer structure of an anion membrane (dioxide material) and a gas diffusion layer (supported anode catalyst) is used between the cell bodies 1 and 2 to realize the gas-solid interface and anion transport (Note: a hot press is required to ensure sufficient contact). A double-layer structure of a cation membrane (nafion115) and a gas diffusion layer (supported cathode catalyst) is used between the cells 2 and 3 to realize the gas-solid interface and cation transport. (Note: It needs to be molded with a heat press to ensure full contact). 3. The cell body 2 is the core component of the solid-state electrolytic cell, with a built-in 3mm-thick square (4cm2) hollow layer, which can be filled with a solid electrolyte to replace the electrolyte and realize the direct preparation of liquid fuel. The solid electrolyte is mainly a high molecular polymer or porous ceramic with good electrical conductivity. The purpose of passing pure water is to take away the liquid product, promote the right shift of the reaction equilibrium and obtain an aqueous solution of the product without impurities. After the substances produced in the No. 1 cell and the substances produced in the No. 3 cell pass through their respective membranes, they are combined in the middle No. 2 cell to form a product, which is carried away by the flowing pure water. | Two-electrode system |
| 28012306-2 |  | On the basis of 28012306-1, a reference electrode is added. The thickness of the reference electrode chamber is 3mm. The solid-state electrolytic cell adopts a sandwich structure as a whole to build a gas-solid interface. Preparation of high-purity liquid product aqueous solutions. | Three-electrode system | |
| 28012306-3 |  | As shown in the figure, on the basis of 28012306-2, the No. 2 plate has been improved, and a serpentine channel has been added. The solid-state electrolytic cell adopts a sandwich structure as a whole, and the gas-solid interface is constructed to replace the electrolyte with a solid electrolyte, avoiding the introduction of anions/cations and directly realizing the preparation of high-purity liquid product aqueous solutions. | Snake channel system | |
| SCI Materials Hub is Committed to Offering The Best Price & Customer Services! | ||||
For international orders, please ask us for quotes via
Email: contact@scimaterials.cn
Tel: +86 153-5789-9751
Clik here to put quick orders on our Alibaba shop
EC603e2 Solid Electrolyte Electrochemical Cell | |||
Product code | Product description | Price | Delivery date |
| 28012306-1 | Two-electrode system | $1736/pc | Ask for quote |
| 28012306-2 | Three-electrode system | $1892.8/pc | Ask for quote |
| 28012306-3 | Snake channel system | $1904/pc | Ask for quote |
| SCI Materials Hub is Committed to Offering The Best Price & Customer Services! | |||
- The price listed above is in U.S. dollars
Worldwide shipping via DHL, SF-Express, FedEx, TNT & other requested carriers.
Payments via Bank Transfer, Paypal, Credit card (via Alibaba), Alipay, Wechat-pay are accepted.
Please contact us for larger quantities or becoming our distributors.
