Toray TGP-H-060 Carbon Paper, Teflon-Treated

  • Product Code:23060101, 23060105, 23060110, 23060120, 23060130, 23060140, 23060150
  • Description:Toray TGP-H-060 Carbon Paper, Teflon-Treated
  • Brand:Toray
  • Lead time:1 day
  • Views:
  • Telephone:+86 153-5789-9751
  • Keywords:Toray TGP-H-060 Carbon Paper, Teflon-Treated, SCI Materials Hub
65.7K

1. Introduction

Toray Paper 060 - TGP-H-060 - is a carbon fiber composite paper suitable for use as a catalyst backing layer. It has a total thickness of 190 um (microns). Toray Paper 060 is a great low-cost alternative to conventional woven carbon cloth Gas Diffusion Layer (GDL) materials.

Toray carbon paper 060 comes with a standard 5% weight wet proofing. The Teflon gives the carbon material a hydrophobic property to better function as an electrode backing material.


Quantity discounts, custom sizes, and custom wet proofing available upon request.


A great substitute for Toray Carbon Paper 060 is AvCarb MGL190. The MGL190 has similar specifications to Toray 060 and is much cheaper per sheet. Similar carbon papers are AvCarb EP40 and AvCarb EP40T.


2. Features

- High conductivity

Carbon fiber bonds to carbon more strongly, resulting in better electrical conduction.

- High strength

The carbon paper is thin, very strong, and offers excellent compression characteristics.

- High gas permeability

Its high porosity (approx. 78%) lets gases flow through the carbon paper smoothly.

- Corrosion resistance

Constituted only by carbon that has been heat-treated at high temperature, the carbon paper contains minimal impurities and exhibits excellent corrosion resistance.

- Smooth surface

As carbon fibers are oriented in surface direction, this material has very smooth surface subject to little irregularities unlike textile.


3. Welcome to cite our materials in your papers

Toray TGP-H-060 with 5wt% PTFE was obtained from SCI Materials Hub.


*** By purchasing this good you agree that you will use the good(s) and their replicas for civilian use only, as described above, and you will never use them for the development or manufacture of weapons of mass destruction such as nuclear, biological or chemical weapons and missiles. If you decide to use the goods for any other application(s), you will immediately notify Toray company in writing before using the goods in such other application(s).

Download:

Toray Carbon Paper 030, 060, 090, and 120 Data Sheet.pdf

Toray carbon paper-MSDS.pdf


Gas Diffusion Layer Properties
Material TypeCarbon Fiber Paper
Thickness0.19 mm (190 microns)
Bulk Density0.44 g/cm3
Porosity (%)78
Gas Permeability1900
Electrical Resistivity (through plane)80 mOhm cm
Flexural Strength (MPa)40
Flexural Modulus (GPa)10
Tensile Strength50
Surface Roughness Ra8 μm (microns)
Electrical Resistivity (in plane)5.8 mOhm cm
Thermal Conductivity (through plane, room temp)(1.7) W/ (mk)
Thermal Conductivity (inplane, room temp)21 W/ (mk)
Thermal Conductivity (inplane, 100°C)23 W/ (mk)
Coefficient of thermal expansion in plane-0.8
PTFE Treatment0wt%, 1wt%, 5wt% (standard), 10wt%, 20wt%, 30wt%, 40wt%, 50wt%
Microporous LayerNone


Electrode base material for fuel cell Physical property table

Product No.Thickness
(mm)
Electrical resistance
mΩcm
Thermal conductivity
W/(m?K)
Gas permeability
ml*mm/
(cm2*hr*
mmAq)
Porosity
(%)
Bulk density
(g/cm3)
Surface roughness
(μm)
Linear expansion coefficient
(Planar direction)
(25~100°C)
(×10-6/°C)
Flexural strength
(MPa)
Flexural modulus
(GPa)
Tensile Strength
(kgf/cm)
Thickness directionPlanar directionThickness direction
(room temperature)
Planar direction
(room temperature)
Planar direction
(100°C)
TGP-H-0300.1180----2500800.48-0.8408-
TGP-H-0600.19805.8-1.721231900780.448-0.840105
TGP-H-0900.28805.6-1.721231700780.448-0.840107
TGP-H-1200.37804.7-1.721231500780.458-0.840108

- The data shown are representative values and not guaranteed

- Contact us separately for the measuring method.

- The standard size is a 400-mm square

Overview

TORAYCA carbon paper is a porous C/C composite (composite material of carbon fiber and carbon) that has been heat-treated at high temperature, whose excellent features make this a favorite base material for fuel cell electrodes and in other electrode applications.

The structure and Generation mechanism of high polymer fuel cells.

The structure and Generation mechanism of high polymer fuel cells.


Generation mechanism of fuel cell

The TORAYCA carbon paper has been used as electrode base material (gas diffusion layer) for phosphoric acid fuel cells and high polymer fuel cells.


Electrode reaction

1) Anode side (fuel electrode): 2H2 → 4H+ + 4e-

2) Cathode side (air electrode): 4H+ + O2 + 4e- → 2H2O

For international orders, please ask us for quotes via

Email: contact@scimaterials.cn

Tel: +86 130-0303-8751 / +86 156-0553-2352


Toray TGP-H-060 Carbon Paper, Teflon-Treated

Product Code

Description

Retail Price (USD$)Lead Time & Availability
23060101

Toray TGP-H-060

1wt% PTFE

$9 (5cm*5cm,Item#:23060101-0505)

$19 (10cm*10cm,Item#:23060101-1010)

$57 (20cm*20cm,Item#:23060101-2020

1 day & In Stock
23060105

Toray TGP-H-060

5wt% PTFE

$9 (5cm*5cm,Item#:23060105-0505)

$19 (10cm*10cmItem#23060105-1010)

$57 (20cm*20cmItem#23060105-2020)

1 day & In Stock
23060110

Toray TGP-H-060

10wt% PTFE

$10 (5cm*5cm,Item#:23060110-0505)

$20 (10cm*10cmItem#23060110-1010)

$60 (20cm*20cmItem#23060110-2020)

1 day & In Stock
23060120

Toray TGP-H-060

20wt% PTFE

$11 (5cm*5cm,Item#:23060120-0505)

$22 (10cm*10cmItem#23060120-1010)

$66 (20cm*20cmItem#23060120-2020)

1 day & In Stock
23060130

Toray TGP-H-060

30wt% PTFE

$12 (5cm*5cm,Item#:23060130-0505)

$24 (10cm*10cmItem#23060130-1010)

$72 (20cm*20cmItem#23060130-2020)

1 day & In Stock
23060140

Toray TGP-H-060

40wt% PTFE

$13 (5cm*5cm,Item#:23060140-0505)

$26 (10cm*10cmItem#23060140-1010)

$78 (20cm*20cmItem#23060140-2020)

1 day & In Stock
23060150

Toray TGP-H-060

50wt% PTFE

$15 (5cm*5cm,Item#:23060150-0505)

$30 (10cm*10cmItem#23060150-1010)

$90 (20cm*20cmItem#23060150-2020)

1 day & In Stock
SCI Materials Hub Is Committed to Offering The Best Price & Customer Services!


Worldwide shipping via DHL, SF-Express & other requested carriers.

Payments via Bank Transfer, Paypal, Credit card (via Taobao), Alipay, Wechat-pay are accepted.
