⚡ The Ultimate Power & Energy Storage Solution
Engineered for mid-to-high-end energy storage and power applications, VoltXpert® LFP-2 is perfectly compatible with aluminum-shell, pouch, and cylindrical batteries. It delivers exceptional energy density and long-term stability—ideal for electric vehicles, stationary storage, and high-drain digital devices.
| 💡 Key Advantage | 📌 Core Performance Highlights |
|---|---|
| High Compaction • Max Storage | Tap density: 2.46±0.02 g/cm³, Bulk density: 1.37 g/cm³ 👉 Packs more energy in limited space—boosts volumetric capacity. |
| Uniform Particle Size • Stable Output | D10: 0.42 μm, D50: 1.12 μm, D90: 4.42 μm 👉 Consistent particle morphology = high production yield and electrochemical stability. |
| Low Resistance • Efficient Discharge | Powder resistivity: 18.92 Ω·cm, Initial efficiency: 99.8% 0.1C: 161.3 mAh/g, 1C: 146.3 mAh/g 👉 Excellent conductivity for fast discharge without loss. |
| Impurity Control • Long Cycle Life | Carbon content: 1.3%, Magnetic impurities: 0.31 ppm 👉 Enhanced cycle stability, safety, and long-term usability. |
| Parameter | Measured Value | Test Method |
|---|---|---|
| Particle Size (D10/D50/D90) | 0.42 / 1.12 / 4.42 μm | Malvern Laser Particle Analyzer |
| Carbon Content | 1.3% | Infrared Carbon-Sulfur Analyzer |
| Powder Resistivity | 18.92 Ω·cm | Four-Point Probe Method |
| Discharge Capacity | 0.1C → 161.3 mAh/g 1C → 146.3 mAh/g | Coin Cell Testing |
| Initial Discharge Efficiency | 99.8% | Half-cell, 2.5–4.1 V |
| Magnetic Impurities | 0.31 ppm | ICP Analysis |
✅ Energy Storage Systems: Grid-level and residential battery banks
✅ Light Mobility: Power tools, e-scooters, low-speed EVs
✅ 3C Electronics: Laptops, drones, smart devices
👉 Ideal for both high-power output and long-duration energy storage applications.
Available Sizes: 5g, 10g, 20g, 50g, 100g, 200g, 500g, 1kg, 2kg, 5kg, 10kg
Storage Conditions: ≤30°C, ≤60% RH
Shelf Life: 12 months in proper storage
Handling Tips: Avoid exposure to moisture, direct sunlight, and mechanical stress
| Quantity Range | Packaging Method | Logistics Description |
|---|---|---|
| < 1kg | Glovebox sealed (vacuum-packed) | Ultra-dry, oxygen-free; ideal for lab research |
| ≥ 1kg | Dry room sealed + vacuum aluminum bag | Batch-ready packaging for industrial or pilot use |
| Component | Typical Ratio (%) | Function |
|---|---|---|
| LFP Active Material | 80–85% | Main energy storage medium |
| Conductive Additive (Super P/CNT) | 5–10% | Enhances electron transfer |
| Binder (PVDF) | 5–10% | Improves film adhesion |
| Solvent (NMP) | As needed | Adjusts viscosity & flow |
Mixing Procedure:
Dissolve PVDF in NMP to form binder solution.
Gradually add LFP powder and conductive agent while stirring.
Use vacuum planetary or high-shear mixer to ensure full dispersion and deaeration.
Ensure slurry uniformity before coating.
Coat slurry evenly on aluminum foil using blade or slot-die coater
Pre-dry at 80–120°C to remove solvent
Perform calendaring (single or multi-pass)
Final drying at ~120°C for 6h
Punch or cut electrodes as required
✅ All operations recommended inside dry room or glovebox (dew point < –40°C)
✅ Keep material sealed and dry at all times, especially for<100g packages
✅ Pre-disperse carbon additives via ultrasonication
✅ Immediately reseal after use to prevent moisture uptake
✅ Clean tools and mixers regularly to avoid contamination
For samples, bulk pricing, or custom solutions:
📞 Hotline: +86-15605532352
📧 Email: contact@scimaterials.cn
📧 Email: contact@scimaterials.cn
📞 Tel: +86 153-7569-8751
🔗 Click to place quick orders via our eBay / Amazon stores.
🌐 We ship worldwide via DHL, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
| Quantity | Packaging Type | Price (USD) | Application Recommendation |
|---|---|---|---|
| 5g | Sealed Bottle | $5.00 | Lab-scale electrode coating |
| 10g | Sealed Bottle | $8.00 | Coin-cell prototyping |
| 20g | Sealed Bottle | $14.00 | Material comparison & formulation screening |
| 50g | Sealed Bottle | $20.00 | Preliminary electrochemical evaluation |
| 100g | Sealed Bottle | $30.00 | Recommended size for academic research |
| 200g | Sealed Bottle | $50.00 | Semi-pilot-scale sample testing |
| 500g | Sealed Bottle | $68.00 | High-volume screening or pilot trials |
| 1kg | Aluminum Foil Bag | $130.00 | Industrial validation, cell prototyping |
| 2kg | Aluminum Foil Bag | $220.00 | Bulk usage for labs and R&D departments |
| 5kg | Aluminum Foil Bag | $500.00 | Pilot production and scale-up sourcing |
| 10kg | Aluminum Foil Bag | $900.00 | Volume procurement with discounted pricing |
