Engineered for Fast-Charging & High-Power Lithium-Ion Batteries
VoltXpert® SO1350 is a next-generation pre-lithiated silicon oxide (SiOx) anode material, designed specifically for fast-charging and high-power applications. Manufactured with advanced particle control and high-purity processing, it offers ultra-high reversible capacity (≥1350 mAh/g), excellent initial Coulombic efficiency (≥89.5%), and superior rate performance, making it ideal for consumer electronics and high-power battery systems.
| Category | Performance | Value |
|---|---|---|
| 🔋 High Capacity | ≥1350 mAh/g | Significantly increases energy density |
| ⚡ High ICE | Initial Coulombic Efficiency ≥89.5% | Minimizes irreversible capacity loss |
| 🚀 Rate Performance | Excellent rate capability | Supports high current charge/discharge |
| 🔌 Broad Compatibility | Suitable for pouch, cylindrical cells | Versatile for different manufacturing formats |
| Item | Value | Benefit |
|---|---|---|
| Reversible Capacity | ≥1350 mAh/g | High energy output |
| Initial Coulombic Efficiency | ≥89.5% | Improved material utilization |
| Rate Capability | Excellent | Stable under fast cycling |
| Parameter | Value | Technical Advantage |
|---|---|---|
| Carbon Content | 4.0 ± 1.0% | Enhances electrical conductivity |
| Moisture | ≤0.5% | Reduces side reactions |
| Residual Alkali (LiOH/Li₂CO₃) | ≤0.3% each | Prevents corrosion and degradation |
| Fe Impurity | ≤100 ppm | Mitigates lithium plating risks |
| Co/Ni/Cu/Zn Impurities | ≤20 ppm each | Ensures cycle life stability |
| Magnetic Impurities (Total) | ≤6 ppm | Lowers internal short circuit risks |
| Environmental Compliance | RoHS compliant | Safe for global applications |
| Property | Value | Relevance |
|---|---|---|
| Particle Size D10 | 4.5 ± 1.0 μm | Enables uniform slurry dispersion |
| Particle Size D50 | 7.5 ± 1.0 μm | Key for coating uniformity |
| Particle Size D90 | 11.8 ± 1.5 μm | Ensures structural integrity |
| Max Particle Size D100 | ≤30 μm | Reduces aggregation risk |
| Tap Density | 1.25 ± 0.15 g/cm³ | Enhances volumetric energy density |
| BET Surface Area | 1.0 ± 0.5 m²/g | Controls side reactions |
| Large Particle Control | No particles ≥40 μm | Reduces manufacturing defects |
| Crystal Structure | XRD – No impurity peaks | Guarantees phase purity |
| Item | Method/Equipment |
|---|---|
| Particle Size | Malvern MS3000E Laser Particle Analyzer |
| Tap Density | BT-301 Tap Density Analyzer |
| Specific Surface Area | JW-DX Dynamic BET Analyzer |
| Electrochemical Testing | Neware CT3002A System (CR2032 cells) |
| Impurity Elements | ICP (PerkinElmer Avio 500) |
| RoHS Compliance | Verified by third-party labs |
Slurry Ratio Recommendation:
VoltXpert® SO1350 : Super P : Binder = 8 : 1 : 1
Preparation Highlights:
Mix binder with ultrapure water and disperse thoroughly.
Add active material and conductive carbon, grind lightly.
Combine binder slurry and stir for 6+ hours.
Coat onto copper foil and vacuum-dry at 80°C for 12 hours.
Recommended Testing Protocol:
0.1C → 0.02C → 0.01C discharge, followed by 0.1C charge (1.5 V), repeat for 3 cycles.
| Use Case | Strengths |
|---|---|
| 📱 Consumer Electronics | High energy & fast charging, system compatible |
| 🚗 High-Power Batteries | Robust output, supports high current draw |
Packaging: Double-layer vacuum bag + protective carton; customizable upon request.
Transportation: Handle with care. Avoid moisture, mechanical shock, and exposure.
Storage: Store in sealed, dry, and ventilated areas. Reseal after opening.
Shelf Life: 24 months from production date.
For samples, custom specs, or bulk procurement, feel free to reach out:
☎️ Tel: +86-15605532352
📧 Email: contact@scimaterials.cn
🔋 VoltXpert® SO1350 — Powering the future of fast-charging lithium batteries with advanced anode technology.
📧 Email: contact@scimaterials.cn
📞 Tel: +86 153-7569-8751
🔗 Click to place quick orders via our eBay / Amazon stores.
🌐 We ship worldwide via DHL, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
| Product Code | 5g | 10g | 20g | 50g | 100g | 200g | 500g | 1kg |
|---|---|---|---|---|---|---|---|---|
| 22010050 | $30 | $50 | $76 | $116 | $196 | $300 | $480 | $700 |
🧾 Notes: Invoices available. Bulk orders supported.
