🔋 VoltXpert® Battery-Grade Single-Crystal LiNi₀.₅Co₀.₂Mn₀.₃O₂ (4.5 µm) Powder

High Capacity · High Density · Long Cycle Life

1. Product Characteristics

VoltXpert® single-crystal NCM powder is engineered for high energy density, long cycle life, and enhanced safety:

• High Energy Output: Full cell (0.5C, 4.35 V) specific capacity ≥ 175 mAh/g; compaction density ≥ 3.60 g/cm³.

• Long Lifespan: ≥ 2,500 cycles at room temperature and ≥ 1,200 cycles at 45 °C with > 80% capacity retention.

• Excellent Consistency: Narrow particle size distribution (D50 ≈ 4.5 µm) ensures stable electrochemical performance.

• Enhanced Safety: Single-crystal morphology resists particle cracking, minimizing side reactions under high voltage.

• Applications: Digital electronics, notebook batteries, and EV battery systems requiring high specific energy.

2. Key Performance Indicators

3. Storage & Handling Guidelines

1. Storage

   • Keep sealed in a dry, moisture-proof, and light-proof environment (RH ≤ 30%, 15–30 °C).

   • Avoid contact with strong acids, bases, or volatile solvents.

   • For long-term storage, seal in argon or dry air atmosphere.

2. Handling

   • Open packaging in a dry room or glove box (dew point ≤ –40 °C).

   • Minimize exposure to air to prevent moisture uptake and surface carbonation.

   • If moisture absorption occurs, dry under vacuum at 120 °C for 12 h before use.

4. Recommended Slurry & Electrode Fabrication Process

4.1 Cathode Composition (by weight)

• VoltXpert® Single-Crystal NCM Powder: 94 wt%

• Conductive Carbon (Super P or similar): 3 wt%

• Binder (PVDF, dissolved in NMP): 3 wt%

4.2 Slurry Preparation Steps

1. Dry mix the conductive additive with NCM powder (5–10 min using a high-speed mixer).

2. Add PVDF/NMP solution (6–8 wt% PVDF concentration) slowly while stirring in the powder blend.

3. Disperse thoroughly using a planetary vacuum mixer or high-shear mixer for 30–60 min until uniform and smooth.

4. Adjust slurry viscosity to 8,000–12,000 mPa·s depending on coating requirements.

4.3 Coating & Densification

1. Coat slurry onto 15–20 µm aluminum foil (single or double side).

2. Pre-dry at 80 °C with hot air to remove most NMP, then vacuum dry at 120 °C for 12 h.

3. Roll-press to achieve target compaction density (≥ 3.60 g/cm³).

4. Cut into required electrode dimensions and assemble in a dry environment.

5. Recommended Electrolytes

• Conventional System: LiPF₆ in EC:EMC:DEC (1:1:1, v/v/v) + 1 wt% VC

• High-Voltage System: LiPF₆ in FEC:EMC (1:1, v/v) + 2 wt% LiBOB

6. FAQ

Q1: How does single-crystal NCM differ from polycrystalline NCM?
A: Single-crystal particles are mechanically robust, resist cracking during cycling, and are better suited for high-voltage, long-life applications.

Q2: Can it be processed in open air?
A: Not recommended — moisture uptake can lead to surface degradation and performance loss.

Q3: What binder and solvent quality is recommended?
A: Use battery-grade PVDF (e.g., HSV900 or 5130) and high-purity NMP (water content ≤ 50 ppm).
