🔹 Accelerate® Pt₃Co/C Catalyst (55% Pt₃Co on Ketjenblack EC-300J)
The Accelerate® 55% Pt₃Co/Ketjenblack EC-300J catalyst features Pt-Co alloy (Pt₃Co) nanoparticles uniformly dispersed on a high surface area Ketjenblack EC-300J carbon support, with an average particle size of approximately 5.2 nm. This catalyst demonstrates excellent electrochemical activity and high mass activity (MA) in proton exchange membrane fuel cells (PEMFCs), making it ideal for hydrogen oxidation and oxygen reduction reactions.
Key Features:
Uniformly distributed Pt-Co alloy nanoparticles with small particle size
High surface area carbon support ensuring excellent dispersion
Large electrochemical surface area (ECSA) for enhanced reaction kinetics
High mass activity (MA) reducing precious metal usage
Low impurity content suitable for high-performance fuel cell applications
| Parameter | Value |
|---|---|
| Composition | 50 wt% Pt; 5 wt% Co; 45 wt% C |
| Average Particle Size (nm) | 3–5 |
| Electrochemical Surface Area (ECSA, m²/g) | 65 |
| BET Surface Area (m²/g) | 110 |
Dispersion Steps:
Add the Pt₃Co/C catalyst to an appropriate amount of deionized water or ionic liquid-containing solvent.
Stir thoroughly and sonicate for 30–60 minutes to ensure full dispersion.
Optionally, add a binder such as Nafion® to prepare a catalyst ink.
Electrode Coating Steps:
Evenly spray the dispersed catalyst ink onto carbon paper, carbon cloth, or a membrane electrode assembly (MEA).
Adjust the coating thickness based on the desired metal loading.
Dry the coated electrodes at 80–120 °C for 30–60 minutes to ensure good adhesion of the catalyst layer.
Proton exchange membrane fuel cells (PEMFCs): anode or cathode catalyst
Hydrogen oxidation reaction (HOR) and oxygen reduction reaction (ORR) studies
Fuel cell catalyst performance optimization and material development
Q1: How should the catalyst be stored?
A1: Store in a dry, sealed, and cool environment, avoiding high humidity, heat, and direct sunlight.
Q2: Can the catalyst be kept dispersed in solution for a long time?
A2: It is not recommended. Use the dispersed ink within 24 hours to prevent sedimentation or particle agglomeration.
Q3: What advantages does Pt₃Co/C have over Pt/C?
A3: Pt₃Co/C alloy catalysts exhibit higher electrochemical activity and stability in the oxygen reduction reaction (ORR), allowing for reduced precious metal usage.
Q4: How is the catalyst loading determined?
A4: Based on the fuel cell design’s current density and electrode area, typically 0.1–0.5 mg Pt/cm².
Q5: How can adhesion of the catalyst layer be improved after coating?
A5: Increase the binder content or perform hot pressing at 80–120 °C to enhance layer adhesion.
📧 Email: contact@scimaterials.cn
📞 Tel: +86 153-7569-8751
🔗 Click to place quick orders via our eBay / Amazon stores.
🌐 We ship worldwide via DHL, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
📑 Accelerate® Platinum Cobalt on Ketjenblack EC-300J – Specifications & Price List (USD)
| Product Model | 0.5 g | 1 g | 2 g | 5 g | 10 g | Lead Time (days) |
|---|---|---|---|---|---|---|
| Accelerate® PC55C 55% PtCo (3:1) on Ketjenblack EC-300J | $160 | $300 | 550 | 1200 | 2000 | In stock |
Notes:
Prices are for reference only; bulk orders may be negotiated for discounts.
Customized specifications are available upon request.
Parameters: Moisture ≤ 1.0%, Impurities ≤ 500 ppm.
Lead times are indicative; actual delivery may vary depending on production schedule.
