Accelerate® Ir/C catalysts are prepared using Vulcan XC-72R, a high-surface-area carbon black, as the support. Iridium (Ir) nanoparticles are finely dispersed on the carbon matrix, offering excellent stability, corrosion resistance, and catalytic performance.
Iridium, as a precious metal catalyst, is particularly effective for the oxygen evolution reaction (OER) in proton exchange membrane water electrolysis (PEMWE), hydrogen production, and advanced energy storage systems.
The product line includes both low Ir loading (20 wt.%) for high mass activity and high Ir loading (85 wt.%) for enhanced durability, allowing users to select the most suitable composition for their application.
Different Ir loadings
| Composition (Ir/Vulcan XC-72R) | Avg. Particle Size (nm) | Electrochemical Surface Area (ECSA, m²/g) | BET Surface Area (m²/g) |
|---|---|---|---|
| 20 wt.% Ir / 80 wt.% Vulcan XC-72R | 2-3 | ~180 | ~500 |
| 85 wt.% Ir / 15 wt.% Vulcan XC-72R | 4-5 | ~85 | ~145 |
General specifications (common to all grades)
| Parameter | Value |
|---|---|
| Catalyst type | Ir/C (Iridium on Carbon) |
| Support | Vulcan XC-72R |
| Dispersion | Excellent, uniform nanoparticles |
| Electrode compatibility | GDL, metallic substrates, MEA assembly |
Dispersion Steps
Weigh an appropriate amount of Ir/C catalyst and add into an isopropanol/deionized water mixture (volume ratio 3:1).
Sonicate for 30–60 minutes to ensure uniform dispersion.
Add 5 wt.% Nafion® or anion-exchange ionomer as a binder to adjust ionic conductivity.
Electrode Spray Coating
Use a spray gun to coat the dispersion evenly onto gas diffusion layers (GDLs) or metallic substrates.
Dry slowly at 60–80 °C to avoid agglomeration.
Typical Ir loading: 0.5–2.0 mgIr/cm² (adjust according to system requirements).
Proton Exchange Membrane Water Electrolysis (PEMWE): OER anode catalyst.
Hydrogen production & energy storage: Stable performance under long-term operation.
Electrolyzers & fuel cells: Benchmark precious-metal catalyst for performance comparison.
Research & development: Reference catalyst for new hybrid or alloy catalyst studies.
Q1: What is the main difference between 20% and 85% Ir/C catalysts?
A: 20% Ir/C offers higher mass activity, making it ideal for maximizing catalytic efficiency. 85% Ir/C provides greater stability due to higher Ir content, suitable for long-lifetime electrolysis systems.
Q2: How should the catalyst be stored?
A: Store in a dry, sealed container, away from moisture and prolonged air exposure to maintain performance.
Q3: Can Ir/C be combined with other metals?
A: Yes. Iridium catalysts are often alloyed with Ru, Pt, or other metals to further enhance catalytic activity and durability.
Q4: What if agglomeration occurs during spraying?
A: Extend sonication time or increase the proportion of isopropanol in the solvent system to improve dispersion.
📧 Email: contact@scimaterials.cn
📞 Tel: +86 153-7569-8751
🔗 Click to place quick orders via our eBay / Amazon stores.
🌐 We ship worldwide via DHL, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
📑 Accelerate® Iridium on Vulcan XC-72R – Specifications & Price List (USD)
| Product Model | 0.5 g | 1 g | 2 g | 5 g | 10 g | Lead Time (days) |
|---|---|---|---|---|---|---|
| Accelerate® IR20B 20%Ir on Vulcan XC-72R | $150 | $250 | $480 | $1000 | $1800 | In stock |
| Accelerate® IR85B 85%Ir on Vulcan XC-72R | $200 | $360 | $700 | $1500 | $2900 | In stock |
Notes:
Prices are for reference only; bulk orders may be negotiated for discounts.
Customized specifications are available upon request.
Parameters: Moisture ≤ 1.0%, Impurities ≤ 500 ppm.
Lead times are indicative; actual delivery may vary depending on production schedule.
