Al-MCM-41, also known as aluminum-modified MCM-41, belongs to the ExxonMobil M41S family of ordered mesoporous molecular sieves.
While its framework is consistent with pure-silica MCM-41 — featuring a hexagonally ordered mesoporous arrangement, ultrahigh surface area, and large pore volume — the introduction of aluminum atoms into the silica framework brings a key benefit: the formation of tunable Brønsted and Lewis acid sites.
This unique combination of mesoporous mass-transfer efficiency + controllable acidity + excellent thermal / hydrothermal stability makes Al-MCM-41 an indispensable material across catalytic science, organic transformations, environmental remediation, and energy materials.
CTAB molecules self-assemble into micellar templates
Silicon & aluminum precursors condense around the template to form the mesostructured framework
Calcination removes the organic template → open mesoporous channels
The result is a highly ordered hexagonal mesoporous network with tunable acidic active sites and a surface area of 850–900 m²/g.
(applicable to powder / extrudate / pellet forms)
| Property | Specification |
|---|---|
| Appearance | White powder / extrudate / spherical pellets |
| Powder size | 2–5 μm |
| Extrudate size | Length 1–2 cm; diameter Ø 2–3 mm |
| Spherical pellet size | Ø 1–2 / 2–3 / 3–5 mm |
| Relative crystallinity | > 95% |
| Average pore diameter | 2.5–3.5 nm |
| BET surface area | 850–900 m²/g |
| Pore volume | ≈ 1.0 mL/g |
| Thermal stability | 1200 °C |
| Hydrothermal stability | 700 °C |
| Framework | Hexagonal ordered mesoporous |
| Delivery state | Calcined, ready to use |
| Key functional feature | Mesoporous transport + active acid sites |
The Si/Al ratio refers to the molar ratio between SiO₂ and Al₂O₃.
Lower Si/Al → more Al → stronger acidity
Higher Si/Al → less Al → weaker acidity but higher structural stability
| Product Model | Si/Al Ratio | Acid Strength | Recommended Applications |
|---|---|---|---|
| Cerafirst™ MSRQ Al-MCM-41 (Si/Al 10–20) | 10–20 | ★★★★★ Strong | Hydrocracking, heavy oil cracking, waste-plastic pyrolysis |
| Cerafirst™ MSRQ Al-MCM-41 (Si/Al 25–30) | 25–30 | ★★★★☆ | Aromatization, alkylation, olefin polymerization |
| Cerafirst™ MSRQ Al-MCM-41 (Si/Al 35–50) | 35–50 | ★★★★ | Amine catalysis, large-molecule oxidation, CO₂ conversion |
| Cerafirst™ MSRQ Al-MCM-41 (Si/Al 60–70) | 60–70 | ★★★☆ | Organic dye removal, adsorption/separation, environmental purification |
| Cerafirst™ MSRQ Al-MCM-41 (Si/Al 80–100) | 80–100 | ★★☆ | Metal nanoparticle support, confined-space catalysis |
| Cerafirst™ MSRQ Al-MCM-41 (Si/Al 120–150) | 120–150 | ★★ Weak | Drug delivery, energy materials, electro-catalyst support, single-atom catalysis |
Tip: If your priority is framework integrity, metal loading capacity, or confinement effect rather than acidity, we recommend selecting high Si/Al variants or pure-silica MCM-41.
🔹 Heavy-oil upgrading & hydrocarbon cracking
🔹 Aromatization / alkylation / polymerization catalysis
🔹 Noble-metal and single-atom catalyst supports
🔹 VOCs adsorption & industrial wastewater treatment
🔹 Polymer reaction engineering & chromatography packing
🔹 Drug delivery and spatially confined reactions
Al-MCM-41 enables a complete workflow from fundamental research to pilot-scale and industrial use.
✔ Each batch is professionally characterized with strict stability control
✔ Joint laboratories with multiple universities and institutes
✔ Custom services — pore size / Si-Al ratio / shaped carrier manufacturing
✔ Optional enhancements — metal loading, doping, composite frameworks, acidity tuning
Cerafirst™ is committed to providing not just products, but real solutions to scientific and industrial challenges in catalysis and advanced materials.
📧 Email: contact@scimaterials.cn
📞 WhatsApp & Tel: +86 153-7569-8751
🔗 Place quick orders on our eBay / Amazon / Alibaba stores.
🌐 We ship worldwide via DHL, FedEx, UPS, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
| Product Model | Si/Al Ratio (Molar) | 1 g | 5 g | 20 g | 100 g | 200 g | 500 g | Lead Time |
|---|---|---|---|---|---|---|---|---|
| MSRQ-10 | 10–20 | $28 | $70 | $200 | $800 | $1350 | $2680 | In stock |
| MSRQ-25 | 25–30 | $28 | $70 | $200 | $800 | $1350 | $2680 | In stock |
| MSRQ-40 | 35–50 | $28 | $70 | $200 | $800 | $1350 | $2680 | In stock |
| MSRQ-60 | 60–70 | $28 | $70 | $200 | $800 | $1350 | $2680 | In stock |
| MSRQ-90 | 80–100 | $28 | $70 | $200 | $800 | $1350 | $2680 | In stock |
| MSRQ-140 | 120–150 | $28 | $70 | $200 | $800 | $1350 | $2680 | In stock |
| Service Type | Description | Notes |
|---|---|---|
| Shaping | Granules / extrudates / spherical pellets | Size customizable |
| Metal loading | Ni / Co / Cu / Fe / Mo / Pt / Pd / Ru etc. | Adjustable loading |
| Catalyst coating | Support + metal + promoter | Tunable acidity/basicity |
| Particle size control | 0.5 – 30 μm | Agglomeration-controlled |
| Surface modification | Acidic / basic / organic functional groups | For special applications |
✔ Default form: calcined, ready to use
✔ Standard shipment: within 3 working days
✔ Please inform in advance if customs declaration for hazardous goods / invoice is required
