⚡ Product Name: Fluoroethylene Carbonate (FEC)

Alias:
4-Fluoro-1,3-dioxolan-2-one | 4-Fluoro-2-oxo-1,3-dioxolane | 4-Fluoro-1,3-dioxacyclopentan-2-one

CAS No.: 114435-02-8
Molecular Formula: C₃H₃FO₃
Molecular Weight: 106.05

🔬 Product Inspection Data

🧊 Conversion of FEC from Solid to Liquid

FEC has a melting point of approximately 22 °C. When stored below this temperature (e.g., in winter or refrigerated conditions), it may appear as a crystalline solid or powder.

To convert it into liquid form:

• Room Temperature Recovery:
  Place the sample at 25–30 °C for several hours until it naturally melts.

• Mild Heating:
  Seal the container and place it in a water bath at 30–40 °C until fully liquefied.

⚠️ Note: Avoid high temperatures (≥60 °C) and prolonged heating to prevent decomposition.

🌟 Product Description

Fluoroethylene Carbonate (FEC) is a high-performance electrolyte additive with excellent film-forming capability and electrochemical stability.

• Typically a colorless transparent liquid at room temperature, but crystallizes into a white solid below its melting point.

• Widely used in lithium-ion batteries, sodium-ion batteries, and some solid-state battery systems.

• Effectively improves:

  • Cycle life

  • Rate performance

  • Low-temperature performance

📦 Storage Conditions

• Store in a sealed container in a cool, dry, and well-ventilated place

• Avoid direct sunlight, heat, and moisture

• Use promptly after opening

• Remaining material should be stored under argon or nitrogen atmosphere

⚡ Usage Guidelines

• Recommended dosage: 2–10% (v/v), depending on battery system optimization

• Compatible with common carbonate solvents:

  • EC (Ethylene Carbonate)

  • DMC (Dimethyl Carbonate)

  • EMC (Ethyl Methyl Carbonate)

• Works with lithium salts such as LiPF₆ to significantly improve SEI film quality

• Operating conditions:
  Anhydrous and oxygen-free environment (e.g., glovebox)

🧪 Electrolyte Preparation (Reference Procedure)

1. Prepare anhydrous solvents (e.g., EC, EMC, DMC) and high-purity lithium salt (LiPF₆) inside a glovebox

2. Mix solvents according to volume ratio (e.g., EC:DMC:EMC = 1:1:1)

3. Add FEC (typically ~5% v/v) and stir thoroughly

4. Add lithium salt (e.g., 1.0 M LiPF₆) and stir until fully dissolved

5. A stable electrolyte is obtained

❓ FAQ

Q1: What is the role of FEC in electrolytes?
A: FEC forms a stable and dense SEI (Solid Electrolyte Interphase) on electrode surfaces, reducing side reactions and improving cycle life and safety.

Q2: What precautions should be taken during use?
A: FEC is highly hygroscopic and must be handled under inert atmosphere to avoid exposure to moisture and air.

Q3: What is the recommended dosage?
A: Typically 2–10%, depending on the battery system and performance requirements.

Q4: Is FEC suitable for sodium-ion or solid-state batteries?
A: Yes. FEC performs well in sodium-ion batteries and is also being explored for solid-state electrolyte systems.

💰 VoltXpert® Electrolyte Carbonate System – Price Overview

📊 High-Purity Solvents – Price Comparison Table

🧪 Functional Additive Pricing

📦 Packaging Information

• Small sizes (5g–500g): Moisture-proof sealed bottles

• Bulk packaging (10kg): Drum packaging

• FEC: Aluminum bottle / Fluorinated bottle (moisture-resistant)

✅ Support Services

✔ Invoice available
✔ Bulk ordering supported
✔ Custom packaging available

⚠️ Usage & Procurement Recommendations

• All solvents are high-purity / electronic grade, suitable for electrolyte systems

• Recommended pre-use treatment:
  ✔ Drying with 3Å molecular sieves (to further reduce trace moisture)

• FEC is highly hygroscopic:
  ✔ Recommended to purchase in small quantities and use promptly
