🔬 ZJ TEM Pure Carbon Film Copper Grids – Complete Guide

(Thin Pure Carbon Film | Standard Pure Carbon Film | Thick Carbon Film | Indexed Carbon Film)

In Transmission Electron Microscopy (TEM) experiments, the structure and thickness of support films directly determine imaging quality, sample stability, and data reliability.

To meet different requirements such as accelerating voltage, sample type, and dispersion system, the ZJ TEM Pure Carbon Film Copper Grid Series provides a comprehensive range of solutions.

This article systematically explains the four major product categories 👇

🧪 I. Product Overview

The ZJ TEM pure carbon film copper grid series includes:

• ⚡ Thin Pure Carbon Film

• 🧱 Standard Pure Carbon Film

• 🛡️ Thick Carbon Film

• 🧭 Indexed Carbon Film (F1 / F2)

Each type is optimized for specific experimental scenarios.

⚡ II. Thin Pure Carbon Film: High Contrast & High Resolution Choice

🧩 Structure

Structure: Thin Pure Carbon Film + Copper Grid

Compared with standard pure carbon film:

• Carbon layer thickness reduced by ~10 nm

• Significantly lower background interference

• Improved image contrast and clarity

🔬 Key Advantages

• 📉 Lower background noise

• 📈 Higher image contrast

• 🎯 Ideal for high-resolution imaging

🧬 Suitable Samples

• Nanocrystals, quantum dots

• One-dimensional nanomaterials

• Core-shell structures (organic/amorphous coatings)

• Samples dispersed in organic solvents (e.g., chloroform, toluene)

📊 Specifications

🧱 III. Standard Pure Carbon Film: Stable & General-Purpose

🧩 Structure

Structure: Pure Carbon Film + Copper Grid (No Formvar Film)

👉 Key difference:

• ❌ No organic Formvar layer

• ✔ Only carbon layer + grid

⚙️ Advantages

• 🧲 High electrical and thermal conductivity

• 🔥 Excellent heat resistance, less prone to rupture

• 📍 Reduced sample drift

• 🧼 Cleaner background (no polymer interference)

🧪 Applications

• Organic solvent-based samples (chloroform, toluene)

• Routine nanomaterial imaging

• Experiments requiring high stability

📊 Specifications

🛡️ IV. Thick Carbon Film: For High-Voltage TEM

🧩 Structure

Structure: Thick Carbon Film + Formvar Film + Copper Grid

👉 Compared with standard carbon films:

• Thicker carbon layer

• Higher mechanical strength

⚡ Application Background

At 200 kV / 300 kV TEM:

• ⚡ Strong electron beam penetration

• ⚠️ Higher risk of sample damage

👉 Thick carbon films provide:

• 🛡️ Enhanced protection

• 🔒 Reduced film breakage

• 📊 Improved structural stability

📊 Specifications

(Code series: BZ31022a)

🧭 V. Indexed Carbon Film: Precision Localization Tool

🧩 Structure

• Copper grids with coordinate markings (F1 / F2)

• Enables fast and accurate positioning

🔍 Key Benefits

• 🎯 Precise relocation of target areas

• 🔁 Repeatable measurements

• 📸 Improved experimental reproducibility

📌 F1 vs F2

• Different coordinate marking systems

• Adapted to different user preferences

📊 Specifications

📊 VI. Comparison Summary

📦 VII. Usage Guidelines

🔧 01 Handling Instructions

• Operate in a clean environment 🧼

• Use precision TEM tweezers (e.g., EZ5888/9)

• Hold only the edge, never touch the film surface

• Open only one row (5 grids) at a time

👉 ⚠️ Single-use consumables only

🧪 02 Sample Preparation Tips

• Letter side = film side

• Dry samples using IR lamp (LP23030-B)

• Clean surface with air blower (KS18666) before loading

👉 Prevent contamination of TEM

🧊 03 Storage & Technical Support

Storage Conditions:

• 📦 Store in TEM grid box (DZ160)

• 🌑 Keep dry and away from light

• ⏳ Shelf life: 1 year

Technical Support:

• 📱 QR code traceability

• 📊 Data support

• 🧑‍🔬 Professional selection guidance

🎯 VIII. Selection Guide

👉 Choose based on your application:

• High-resolution nanomaterials → ⚡ Thin Pure Carbon Film

• Routine / solvent-based samples → 🧱 Standard Pure Carbon Film

• High-voltage TEM (≥200 kV) → 🛡️ Thick Carbon Film

• Precise positioning required → 🧭 Indexed Carbon Film

🌍 International Orders & Shipping

📧 Email: contact@scimaterials.cn
📞 WhatsApp & Tel: +86 153-7569-8751

🔗 Place quick orders on our eBay / Amazon / Alibaba stores.

🌐 We ship worldwide via DHL, FedEx, UPS, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.

💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay

1️⃣ ZJ TEM Copper Grid Thin Pure Carbon Film

2️⃣ ZJ TEM Copper Grid Standard Pure Carbon Film

3️⃣ ZJ TEM Copper Grid Thick Carbon Film（BZ31022a）

4️⃣ ZJ TEM Coordinate Carbon Film (Indexed Grids)
