🔬 ZJ TEM Dedicated Support Film Series Overview
For Transmission Electron Microscopy (TEM) Sample Preparation and Observation

The ZJ TEM support film series covers multiple mesh sizes, structural forms, and application scenarios, including copper grid micro-lattices, carbon-free Fanghua films, dual-layer grids, and large-field support films. It meets the needs ranging from routine imaging to advanced high-resolution analysis.

🧪 I. TEM Copper Grid Low-Porosity Micro-Lattice Support Films

Porous support films are fabricated by constructing micro-porous structures of different pore sizes on the support film for nanomaterial characterization.
Compared with conventional micro-grids, they provide finer pore structures and enable:

• Effective loading of nanorods / nanowires

• Rapid penetration of dispersants and absorption by filter paper

• Simultaneous observation of low-magnification overall morphology and high-resolution local structure on the same film

👉 Advantages:

• Low-magnification observation of overall dispersion

• High-resolution local structural analysis

• Customizable pore sizes

📌 Features:

• Low-porosity structure improves imaging integrity

• High mechanical strength

• Compatible with standard TEM applications

🧪 II. TEM Carbon-Free Fanghua Films

Fanghua film material: polyvinyl formal (PVA-formaldehyde), soluble in dichloroethane or chloroform.

👉 Advantages:

• Carbon-free background, pure organic film

• Clean imaging background with good flexibility

• Suitable for ultrathin sections and nanopowders

👉 Disadvantages:

• Poor conductivity

• Prone to charging, local carbonization, drift, or rupture

👉 Recommended: ≤100 kV TEM operation

📌 Features:

• Carbon-free background, high-resolution friendly

• Ultra-low contamination background

• Suitable for nanoparticles and ultrathin samples

🧪 III. TEM Dual-Layer Grid Support Films

Structure: Carbon film + Fanghua film + dual-layer grid

👉 Features:

• Sandwich structure (sample is held between layers)

• Suitable for large particles and drift-prone samples

• Especially suitable for magnetic materials

• Prevents magnetic-field-induced sample movement

• Reduces contamination in TEM systems

📌 Features:

• Dual-layer clamping structure

• Strong anti-drift performance

• Suitable for magnetic / large-particle samples

🧪 IV. TEM Large Field-of-View Carbon Support Films

Structure: Carbon film + Fanghua film + large-field grid

👉 Features:

• Ultra-large observation window

• High flatness and mechanical strength

• Suitable for micron-scale and large-structure samples

• Supports 3D reconstruction analysis

• Ideal for biological sections and long nanowires

1️⃣ Aperture Grid Support Films

2️⃣ Slit Grid Support Films

⚙️ V. Handling Procedure

• Operate in a clean environment

• Slide out only ~5 pieces each time

• Use fine tweezers to grasp edges

• Avoid touching the film surface

• Seal immediately after use

• Single-use consumable

🧫 VI. Sample Preparation Guidelines

• Lettered side is the film side (front surface)

• Place sample on the front side

• Use filter paper or sample holder

• Pre-dry with infrared lamp

• Remove dust before loading into TEM

• Use reflectivity to distinguish orientation

📦 VII. Storage and Service

• Dedicated TEM sample box storage

• Sealed, moisture-proof, and light-proof

• Shelf life: 1 year

• Full batch traceability

• Retain samples and data for technical support

✅ Summary

This product series covers:

✔ Porous / carbon-free / dual-layer / large-field structures
✔ Full mesh range from 50 to 400 mesh
✔ Complete TEM application scenarios

Applicable to:

• Nanomaterials

• Catalytic materials

• Biological samples

• Battery materials

• Magnetic particle systems

🌍 International Orders & Shipping

📧 Email: contact@scimaterials.cn
📞 WhatsApp & Tel: +86 153-7569-8751

🔗 Place quick orders on our eBay / Amazon / Alibaba stores.

🌐 We ship worldwide via DHL, FedEx, UPS, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.

💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay

1. ZJ TEM Specialized Copper Grid Low-Porosity Microgrid Support Film

Domestic copper grid low-porosity microgrid support film for TEM grids (Zhongke Instrument)

2. ZJ TEM Specialized Carbon-Free Square Hole Film

3. ZJ TEM Specialized Double-Layer Grid Support Film

4. ZJ TEM Large Field-of-View Carbon Support Film (Aperture Grid)

5. ZJ TEM Large Field-of-View Carbon Support Film (Slit Grid)
