TEM Grid Selection Guide: Materials, Structures, and Specifications (Comprehensive Overview)
In Transmission Electron Microscope (TEM) experiments, grids may be small, but they are a critical carrier that directly determines imaging quality. Different materials, aperture sizes, and structural designs will directly affect electron beam transmission, sample stability, and final image performance.
This article provides a systematic overview of material properties, structural types, application scenarios, and complete specification tables.
Single-hole ring aperture range: 75–2000 μm
Common materials include:
Copper (Cu)
Nickel (Ni)
Gold (Au)
Molybdenum (Mo)
Titanium (Ti)
Aluminum (Al)
Platinum (Pt)
Main applications:
Block sample support
Observation after ion milling / twin-jet polishing
Biological section support
Among them:
👉 Copper grids = most commonly used (low cost + non-magnetic)
Independently designed (with “Z” mark for front/back identification)
High strength + large field of view
Multiple structure options:
Square mesh / circular hole / aperture
Slot / double / parallel
Custom materials supported:
Aluminum (Al)
Tungsten (W)
Stainless steel (SS)
| Material | Advantages | Disadvantages | Recommended Use |
|---|---|---|---|
| Copper Cu | Low cost, non-magnetic | Corrodes in acidic conditions | Routine TEM |
| Nickel Ni | High strength | Magnetic | Special structures |
| Gold Au | Chemically stable | Soft, expensive | High-precision experiments |
| Molybdenum Mo | High-temp resistant, strong | Expensive | High-temperature environments |
Direct use
Used for picking biological samples
Followed by carbon coating
Covered with organic film
Prevents sample loss
Improves adhesion
NO.1 Large loading area + double structure prevents sample loss
NO.2 Double-sided usability, no need to distinguish orientation
NO.3 Improves electron beam transmission
NO.4 Foldable for space-saving storage
Supports multiple film types
Suitable for strip-shaped samples
Less obstruction, clearer imaging
Enables positioning
Strip materials
Single cells / serial sections
EDS analysis → Avoid copper grids
Biological experiments → Use gold/nickel
High-temperature experiments → Use molybdenum
Front/back identification → Gold/palladium dual grids
| Specification | Code | Status |
|---|---|---|
| 0.1 mm Cu ring | AZA100-01 | Out of stock |
| 0.15 mm Cu ring | AZA100-015 | Out of stock |
| 0.2 mm Cu ring | AZA100-02 | Out of stock |
| 0.3 mm Cu ring | AZA100-03 | In stock |
| 0.5 mm Cu ring | AZA100-05 | In stock |
| 0.6 mm Mo ring 30μm | AZM060 | In stock |
| 0.8 mm Cu ring | AZA100-08 | In stock |
| 0.8 mm Mo ring 30μm | AZM080 | In stock |
| 1.0 mm Cu ring | AZA100-10 | Out of stock |
| 1.0 mm Mo ring 30μm | AZM100 | In stock |
| 1.2 mm Cu ring | AZA100-12 | In stock |
| 1.2 mm Mo ring 30μm | AZM120 | In stock |
| 1.5 mm Cu ring | AZA100-15 | Out of stock |
| 1.5 mm Mo ring 30μm | AZM150 | In stock |
| 1.8 mm Cu ring | AZA100-18 | In stock |
| 1.8 mm Mo ring 30μm | AZM180 | In stock |
| 2.0 mm Cu ring | AZA100-20 | In stock |
| 2.0 mm Mo ring 30μm | AZM200 | In stock |
| Specification | Code | Status |
|---|---|---|
| 1.0 + 1.0 mm | AZDA10/10 | In stock |
| 1.5 + 1.0 mm | AZDA15/10 | In stock |
| 1.5 + 1.5 mm | AZDA15/15 | In stock |
| 1.8 + 1.4 mm | AZDA18/14 | Out of stock |
| 2.0 + 1.5 mm | AZDA20/15 | In stock |
| 2.0 + 1.8 mm | AZDA20/18 | In stock |
| Specification | Code | Status |
|---|---|---|
| 0.5×0.2 mm | AZS0502 | Out of stock |
| 0.5×0.3 mm | AZS0503 | Out of stock |
| 1.0×0.2 mm | AZS102 | In stock |
| 1.0×0.3 mm | AZS103 | Out of stock |
| 1.5×0.3 mm | AZS1503 | In stock |
| 2.0×0.3 mm (Mo) | AZS203M | In stock |
| 2.0×0.5 mm (Mo) | AZS205M | In stock |
| 2.0×0.5 mm | AZS205 | Out of stock |
| 2.0×0.75 mm | AZS2075 | In stock |
| 2.0×1.0 mm | AZS21 | Out of stock |
| 2.0×1.5 mm | AZS215 | In stock |
| 2.1×1.6 mm | AZS2116 | Out of stock |
| Specification | Code | Status |
|---|---|---|
| 50 mesh | AZ50 | Out of stock |
| 75 mesh | AZ75 | Out of stock |
| 100 mesh | AZ100 | In stock |
| 150 mesh | AZ150 | In stock |
| 200 mesh | AZ200 | In stock |
| Specification | Code | Status |
|---|---|---|
| 50 / 50 mesh | AZD50/50 | In stock |
| 50 / 100 mesh | AZD50/100 | In stock |
| 100 / 100 mesh | AZD100/100 | In stock |
| 100 / 200 mesh | AZD100/200 | In stock |
| 200 / 200 mesh | AZD200/200 | In stock |
📧 Email: contact@scimaterials.cn
📞 WhatsApp & Tel: +86 153-7569-8751
🔗 Place quick orders on our eBay / Amazon / Alibaba stores.
🌐 We ship worldwide via DHL, FedEx, UPS, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
| Specification | Code | Status | Price (USD) |
|---|---|---|---|
| 0.1 mm Copper Single Hole Ring | AZA100-01 | Out of Stock | 22.5 |
| 0.15 mm Copper Single Hole Ring | AZA100-015 | Out of Stock | 22.5 |
| 0.2 mm Copper Single Hole Ring | AZA100-02 | Out of Stock | 22.5 |
| 0.3 mm Copper Single Hole Ring | AZA100-03 | In Stock | 22.5 |
| 0.5 mm Copper Single Hole Ring | AZA100-05 | In Stock | 22.5 |
| 0.6 mm Molybdenum Ring 30μm | AZM060 | In Stock | 105 |
| 0.8 mm Copper Single Hole Ring | AZA100-08 | In Stock | 22.5 |
| 0.8 mm Molybdenum Ring 30μm | AZM080 | In Stock | 105 |
| 1.0 mm Copper Single Hole Ring | AZA100-10 | Out of Stock | 22.5 |
| 1.0 mm Molybdenum Ring 30μm | AZM100 | In Stock | 105 |
| 1.2 mm Copper Single Hole Ring | AZA100-12 | In Stock | 22.5 |
| 1.2 mm Molybdenum Ring 30μm | AZM120 | In Stock | 105 |
| 1.5 mm Copper Single Hole Ring | AZA100-15 | Out of Stock | 22.5 |
| 1.5 mm Molybdenum Ring 30μm | AZM150 | In Stock | 105 |
| 1.8 mm Copper Single Hole Ring | AZA100-18 | In Stock | 22.5 |
| 1.8 mm Molybdenum Ring 30μm | AZM180 | In Stock | 105 |
| 2.0 mm Copper Single Hole Ring | AZA100-20 | In Stock | 22.5 |
| 2.0 mm Molybdenum Ring 30μm | AZM200 | In Stock | 105 |
| Specification | Code | Status | Price (USD) |
|---|---|---|---|
| 1.0 + 1.0 mm | AZDA10/10 | In Stock | 36 |
| 1.5 + 1.0 mm | AZDA15/10 | In Stock | 36 |
| 1.5 + 1.5 mm | AZDA15/15 | In Stock | 36 |
| 1.8 + 1.4 mm | AZDA18/14 | Out of Stock | 36 |
| 2.0 + 1.5 mm | AZDA20/15 | In Stock | 36 |
| 2.0 + 1.8 mm | AZDA20/18 | In Stock | 36 |
| Specification | Code | Status | Price (USD) |
|---|---|---|---|
| 0.5 × 0.2 mm | AZS0502 | Out of Stock | 22.5 |
| 0.5 × 0.3 mm | AZS0503 | Out of Stock | 22.5 |
| 1.0 × 0.2 mm | AZS102 | In Stock | 22.5 |
| 1.0 × 0.3 mm | AZS103 | Out of Stock | 22.5 |
| 1.5 × 0.3 mm | AZS1503 | In Stock | 22.5 |
| 2.0 × 0.3 mm (Mo) | AZS203M | In Stock | 66 |
| 2.0 × 0.5 mm (Mo) | AZS205M | In Stock | 66 |
| 2.0 × 0.5 mm | AZS205 | Out of Stock | 22.5 |
| 2.0 × 0.75 mm | AZS2075 | In Stock | 22.5 |
| 2.0 × 1.0 mm | AZS21 | Out of Stock | 22.5 |
| 2.0 × 1.5 mm | AZS215 | In Stock | 22.5 |
| 2.1 × 1.6 mm | AZS2116 | Out of Stock | 22.5 |
| Specification | Code | Status | Price (USD) |
|---|---|---|---|
| 50 mesh | AZ50 | Out of Stock | 22.5 |
| 75 mesh | AZ75 | Out of Stock | 22.5 |
| 100 mesh | AZ100 | In Stock | 22.5 |
| 150 mesh | AZ150 | In Stock | 22.5 |
| 200 mesh | AZ200 | In Stock | 22.5 |
| Specification | Code | Status | Price (USD) |
|---|---|---|---|
| 50 / 50 mesh | AZD50/50 | In Stock | 36 |
| 50 / 100 mesh | AZD50/100 | In Stock | 36 |
| 100 / 100 mesh | AZD100/100 | In Stock | 36 |
| 100 / 200 mesh | AZD100/200 | In Stock | 36 |
| 200 / 200 mesh | AZD200/200 | In Stock | 36 |
