Millipore Omnipore™ and Fluoropore™ are both PTFE (polytetrafluoroethylene) microporous membrane series under Merck Millipore, designed for applications requiring high chemical compatibility. Omnipore™ is a hydrophilic PTFE membrane that can be used directly for aqueous solutions, acidic solutions, alkaline solutions, and a wide range of organic solvents. Fluoropore™ is a hydrophobic PTFE membrane, typically laminated with a polyethylene/polypropylene support layer, suitable for acid, alkali, and solvent clarification, air monitoring, gas filtration, and venting applications. The manufacturer specifically notes that Fluoropore™ catalog numbers containing "FHUP" are unsupported/non-laminated structures.
| Feature | Omnipore™ Hydrophilic PTFE Membrane | Fluoropore™ Hydrophobic PTFE Membrane |
|---|---|---|
| Material | Hydrophilic PTFE (polytetrafluoroethylene) | Hydrophobic PTFE (polytetrafluoroethylene), commonly with polyethylene/polypropylene support layer |
| Wettability | Hydrophilic, ready-to-use for aqueous samples | Hydrophobic, suitable for organic solvents, gas filtration, venting, and air monitoring |
| Chemical Compatibility | Compatible with nearly all solvents, acids, and alkaline solutions | Broad chemical compatibility, suitable for acids, bases, and solvent clarification |
| Porosity Advantage | High porosity provides high flow rates | High porosity provides high flow rates and consistent performance |
| Typical Applications | Aqueous solution filtration, acid/base solution clarification, HPLC/UPLC/LC-MS/MS mobile phase filtration, microplastic analysis | Acid/base/solvent clarification, air monitoring, gas filtration and venting, UV spectroscopy, particle monitoring, mobile phase filtration |
| Suitable Samples | Aqueous samples, acidic/alkaline samples, polar/non-polar solvent samples | Organic solvent samples, aggressive chemicals, gases or venting systems |
| Sterility | Commonly supplied non-sterile; verify by specific catalog number | Commonly supplied non-sterile; verify by specific catalog number |
The following parameters are compiled from Merck Millipore official product performance sheets. The Filter Code typically corresponds to the first four digits of the catalog number. Bubble point test conditions are based on methanol. Omnipore™ flow performance data are reference values for 47 mm discs at 20°C under 8.97" Hg vacuum, filtering 100 mL of water.
| Series | Membrane Property | Filter Code | Pore Size | Bubble Point | Thickness | Reference Flow Performance | Air Flow Rate | Max Operating Temp | Porosity | Typical Applications |
|---|---|---|---|---|---|---|---|---|---|---|
| Fluoropore™ | Hydrophobic PTFE | FGLP | 0.2 μm | 1.0 bar | 150 μm | 24 mL/min/cm² | 5 L/min/cm² | 130°C | 85% | Acid/base/solvent clarification, air monitoring, gas filtration, UV spectroscopy |
| Fluoropore™ | Hydrophobic PTFE | FHLP | 0.45 μm | 0.63 bar | 150 μm | 60 mL/min/cm² | 8 L/min/cm² | 130°C | 85% | Acid/base/solvent clarification, air monitoring, gas filtration, UV spectroscopy |
| Fluoropore™ | Hydrophobic PTFE | FALP | 1.0 μm | 0.5 bar | 150 μm | 110 mL/min/cm² | 16 L/min/cm² | 130°C | 85% | Coarse particle filtration, solvent pre-filtration, gas filtration |
| Fluoropore™ | Hydrophobic PTFE | FSLW | 3.0 μm | 1.0 bar | 150 μm | 286 mL/min/cm² | 20 L/min/cm² | 130°C | 85% | High-flow pre-filtration, particle monitoring, gas venting |
| Fluoropore™ | Hydrophobic PTFE, unsupported | FHUP | 0.45 μm | 0.63 bar | 50 μm | 75 mL/min/cm² | 9 L/min/cm² | 130°C | N/A | Specialized filtration requiring unsupported PTFE membrane |
| Omnipore™ | Hydrophilic PTFE | JVWP | 0.1 μm | 23.6 bar | 30 μm | 100 | — | Refer to specific catalog | Refer to specific catalog | Fine particle retention, acid/base solution clarification, aqueous filtration |
| Omnipore™ | Hydrophilic PTFE | JGWP | 0.2 μm | 13.6 bar | 65 μm | 50 | — | Typically 130°C | Typically 80% | Aqueous filtration, mobile phase filtration, microplastic analysis |
| Omnipore™ | Hydrophilic PTFE | JHWP | 0.45 μm | 7.9 bar | 65 μm | 15 | — | Refer to specific catalog | Refer to specific catalog | General clarification, acid/base solution filtration |
| Omnipore™ | Hydrophilic PTFE | JAWP | 1.0 μm | 3.6 bar | 85 μm | 5 | — | Refer to specific catalog | Refer to specific catalog | Coarse particle removal, sample pre-filtration |
| Omnipore™ | Hydrophilic PTFE | JMWP | 5.0 μm | 2.1 bar | 85 μm | 1.5 | — | Refer to specific catalog | Refer to specific catalog | Large particle removal, rapid pre-filtration |
| Omnipore™ | Hydrophilic PTFE | JCWP | 10.0 μm | 0.7 bar | 85 μm | 0.5 | — | Refer to specific catalog | Refer to specific catalog | Large particle sample clarification, pretreatment filtration |
Omnipore™ is better suited for applications that require direct filtration of aqueous systems, such as aqueous solution filtration, acidic solution clarification, alkaline solution clarification, HPLC/UPLC/LC-MS/MS mobile phase filtration, and microplastic analysis. Its hydrophilic PTFE material combines the chemical inertness of PTFE with compatibility for aqueous samples, making it ideal for filtration scenarios that demand high chemical compatibility without the need for additional pre-wetting steps.
Fluoropore™ is better suited for organic solvents, strong acids/bases, gas filtration, and air monitoring applications, including acid/base/solvent clarification, venting and exhaust gas filtration, UV spectroscopy sample preparation, particle monitoring, microplastic analysis, and HPLC/UPLC/LC-MS/MS mobile phase filtration. Because hydrophobic PTFE does not wet naturally with water, aqueous samples typically require pre-wetting according to protocol or the use of Omnipore™ hydrophilic PTFE instead.
| Application Scenario | Recommended Series | Recommended Pore Size | Selection Rationale |
|---|---|---|---|
| Direct aqueous solution filtration | Omnipore™ | 0.2 μm / 0.45 μm | Hydrophilic PTFE, suitable for aqueous samples, no complex pre-wetting required |
| Acid/base solution clarification | Omnipore™ or Fluoropore™ | 0.2 μm / 0.45 μm | Both offer good chemical inertness; Omnipore™ preferred for aqueous acid/base, Fluoropore™ for non-aqueous systems |
| Organic solvent filtration | Fluoropore™ | 0.2 μm / 0.45 μm | Hydrophobic PTFE offers good compatibility with most organic solvents |
| HPLC/UPLC/LC-MS/MS mobile phase filtration | Omnipore™ or Fluoropore™ | 0.2 μm / 0.45 μm | Select hydrophilic or hydrophobic PTFE based on mobile phase aqueous/organic ratio |
| Air monitoring / gas filtration | Fluoropore™ | 0.45 μm / 1.0 μm / 3.0 μm | Hydrophobic PTFE allows gas passage and venting protection |
| Coarse particle pre-filtration | Omnipore™ or Fluoropore™ | 1.0 μm / 3.0 μm / 5.0 μm / 10.0 μm | Larger pores provide higher flow rates, suitable for sample pretreatment |
| Fine particle retention | Omnipore™ | 0.1 μm / 0.2 μm | Smaller pores offer stronger retention, suitable for high-precision filtration |
In general, 0.1 μm, 0.2 μm, or 0.22 μm are commonly used for applications requiring higher retention, while 0.45 μm is commonly used for routine clarification. Membrane pore size affects both retention capability and flow rate — smaller pores provide stronger retention but typically result in slower filtration speeds.
Select the appropriate pore size based on sample type: 0.45 μm for routine clarification, or 0.2 μm/0.1 μm for high-precision particle removal.
Place the membrane flat into the filter holder, ensuring it is free from wrinkles, damage, and contamination.
Pre-wet the membrane with a small volume of the sample solution or a compatible solvent to eliminate air bubbles from the membrane surface.
Pour the sample into the filter funnel and begin filtration using vacuum filtration, positive pressure, or a filter holder setup.
After filtration, collect the filtrate or retain the membrane surface particles for subsequent analysis based on the experimental objective.
For organic solvent filtration, select the appropriate pore size Fluoropore™ membrane directly.
If aqueous samples must be filtered with hydrophobic PTFE, pre-wet the membrane with methanol, ethanol, or another compatible organic solvent first, then rinse with water or buffer. If pre-wetting is not desired, Omnipore™ is recommended instead.
For gas filtration or venting applications, confirm gas flow direction, pressure range, and seal integrity to avoid membrane damage from overpressure.
Before filtering aggressive solutions, verify the chemical compatibility of the entire system, including the membrane, support layer, gaskets, filter funnel, and connectors.
After use, dispose of the membrane according to sample hazard classification and laboratory safety regulations to avoid secondary contamination from residual solvents, acids/bases, or hazardous particles.
| Precautions | Description |
|---|---|
| Distinguish hydrophilic/hydrophobic | For aqueous samples, prioritize Omnipore™; for organic solvents and gas filtration, prioritize Fluoropore™ |
| Note FHUP special structure | Fluoropore™ catalog numbers containing "FHUP" are unsupported/non-laminated; their mechanical support differs from standard laminated versions |
| Avoid membrane surface damage | Use clean forceps to handle the membrane by the edges to prevent fingerprints, oil contamination, or creases from affecting performance |
| Control filtration pressure | Excessive pressure may cause membrane deformation, rupture, or increased particle breakthrough |
| Pre-filter high-particle samples | For turbid samples, use a larger pore size membrane or pre-filter to reduce clogging |
| Verify full-system compatibility | PTFE membranes have high chemical compatibility, but filter holders, gaskets, support layers, and connectors must also be compatible with the sample |
| Non-sterile ≠ sterile filtration ready | Most disc membranes are supplied non-sterile; if used for microbiological applications, confirm sterilization method and application requirements |
Q1: What is the main difference between Omnipore™ and Fluoropore™?
A: Omnipore™ is a hydrophilic PTFE membrane, suitable for aqueous solutions, acidic/alkaline solutions, and samples with higher aqueous content. Fluoropore™ is a hydrophobic PTFE membrane, suitable for organic solvents, gas filtration, venting, and air monitoring.
Q2: Should I choose Omnipore™ or Fluoropore™ for water samples?
A: Omnipore™ is the preferred choice. If Fluoropore™ is used for aqueous samples, pre-wetting with a compatible organic solvent is typically required; otherwise, water will not naturally pass through the hydrophobic PTFE membrane.
Q3: Which membrane should I choose for organic solvent filtration?
A: Fluoropore™ hydrophobic PTFE is generally recommended. If the sample contains a significant aqueous phase, Omnipore™ hydrophilic PTFE may also be considered depending on the system composition.
Q4: How do I choose between 0.2 μm and 0.45 μm?
A: 0.2 μm is better suited for high-retention requirements, fine particle removal, and instrumental analysis sample preparation. 0.45 μm is better for routine clarification, offering faster flow rates and lower clogging tendency.
Q5: Can Fluoropore™ be used for air monitoring?
A: Yes. Air monitoring, venting and exhaust gas filtration, and UV spectroscopy are among the applications listed by the manufacturer. The hydrophobic PTFE structure is suitable for gas passage and related particle collection applications.
Q6: Can Omnipore™ filter strong acids and bases?
A: Omnipore™ hydrophilic PTFE is described by the manufacturer as compatible with nearly all solvents, acids, and alkaline solutions. However, in practice, the entire filtration system — including holders, seals, and connectors — should also be verified for compatibility with the specific acid/base system.
Q7: What is the difference between FHUP and standard Fluoropore™?
A: FHUP is an unsupported/non-laminated structure with a thinner profile, suitable for specific experimental needs. Standard Fluoropore™ is typically laminated with a support layer, offering better mechanical handling performance for routine use.
Millipore Omnipore™ and Fluoropore™ are both high-chemical-compatibility PTFE membrane products. For filtering aqueous solutions, acid/base aqueous systems, mobile phases, and microplastic samples, prioritize Omnipore™ hydrophilic PTFE. For filtering organic solvents, aggressive solvents, gases, air samples, or venting protection applications, prioritize Fluoropore™ hydrophobic PTFE. When making a final selection, consider the sample matrix, pore size, flow rate requirements, need for a support layer, filtration pressure, membrane diameter, and overall filtration device compatibility.
