Millipore Durapore™ is a classic PVDF (polyvinylidene fluoride) microporous membrane series under Merck Millipore, offering high flow rates, high throughput, low extractables, and broad chemical compatibility. Durapore™ is available in both hydrophilic and hydrophobic versions, allowing selection based on different experimental scenarios including aqueous samples, protein samples, solvent samples, gas filtration, and air/gas sterilization. According to manufacturer documentation, hydrophilic Durapore™ PVDF membranes exhibit lower protein binding compared to nylon, nitrocellulose, or PTFE membranes, making them suitable for applications where minimizing sample loss and maximizing recovery are priorities.
| Feature | Durapore™ Hydrophilic PVDF Membrane | Durapore™ Hydrophobic PVDF Membrane |
|---|---|---|
| Material | PVDF (polyvinylidene fluoride) | PVDF (polyvinylidene fluoride) |
| Surface Property | Hydrophilic, suitable for aqueous samples and biological solutions | Hydrophobic, suitable for gases, air, solvents, and venting filtration |
| Protein Binding | Low protein binding, suitable for high-recovery sample filtration | Higher protein binding than hydrophilic version; typical specification: 150 μg/cm² |
| Typical Applications | Bioburden reduction filtration of biological solutions, protein solution filtration, buffer filtration, aqueous sample clarification, microorganism retention | Air sterilization, gas sterilization, solvent filtration, venting protection, hydrophobic barrier filtration |
| Flow Performance | High water flow rate, suitable for liquid filtration | Good air flow performance; aqueous liquids typically require pre-wetting with compatible solvents such as methanol |
| Suitable Samples | Aqueous solutions, buffers, protein samples, biopharmaceutical pretreatment | Organic solvents, air, gases, non-aqueous samples |
| Common Color/Surface | White, plain surface | White, plain surface |
| Sterilizable | Autoclavable, EtO, or gamma sterilizable; verify by specific catalog number | Autoclavable, EtO, or gamma sterilizable; verify by specific catalog number |
The following parameters are compiled from Merck Millipore Durapore™ official product performance sheets and representative product pages. The Filter Code typically corresponds to the first four digits of the catalog number; actual ordering requires verification of diameter, pack size, and catalog number suffix. Durapore™ general specifications include: white color, plain surface, typical thickness 125 μm, maximum operating temperature 85°C, weight extractables<0.5%, and sterilization options including autoclaving, EtO, or gamma irradiation.
| Series | Filter Code | Pore Size | Wettability | Bubble Point | Water Flow Rate | Air Flow Rate | Protein Binding | Typical Applications |
|---|---|---|---|---|---|---|---|---|
| Durapore™ PVDF | VVLP | 0.1 μm | Hydrophilic | ≥75 psi, air/water | >4 mL/min/cm² | — | 4 μg/cm² | Fine particle retention, sterile-grade liquid filtration, biological solution filtration |
| Durapore™ PVDF | GVWP | 0.22 μm | Hydrophilic | ≥50 psi, air/water; representative page: ≥3.45 bar | >12 mL/min/cm²; 25 mm representative: >1 mL/min/cm² | 2 L/min/cm² | 4 μg/cm² | Bioburden reduction filtration of biological solutions, protein sample filtration, buffer filtration |
| Durapore™ PVDF | HVLP | 0.45 μm | Hydrophilic | ≥22 psi, air/water; representative page: ≥1.55 bar | >34 mL/min/cm²; 90 mm representative: >2.6 mL/min/cm² | 4 L/min/cm² | 4 μg/cm² | Routine clarification filtration, microorganism retention, particle monitoring |
| Durapore™ PVDF | DVPP | 0.65 μm | Hydrophilic | ≥15 psi, air/water | >78 mL/min/cm² | — | 4 μg/cm² | Large particle removal, microorganism retention, rapid clarification filtration |
| Durapore™ PVDF | SVLP | 5.0 μm | Hydrophilic | ≥3 psi, air/water | >208 mL/min/cm² | — | 4 μg/cm² | Biological solution clarification, particle monitoring, sample pre-filtration |
| Durapore™ PVDF | VVHP | 0.1 μm | Hydrophobic | ≥26 psi, air/methanol | — | 0.9 L/min/cm² | 150 μg/cm² | Gas filtration, air filtration, fine particle barrier |
| Durapore™ PVDF | GVHP | 0.22 μm | Hydrophobic | ≥18 psi, air/methanol; representative page: ≥1.24 bar | Water flow measurable after methanol pre-wetting | 1.7 L/min/cm²; 90 mm representative: ≥16 mL/min/cm² Gurley | 150 μg/cm² | Air sterilization, gas sterilization, solvent filtration |
| Durapore™ PVDF | HVHP | 0.45 μm | Hydrophobic | ≥9 psi, air/methanol | — | 4.9 L/min/cm² | 150 μg/cm² | Solvent filtration, gas filtration, venting protection |
Durapore™ hydrophilic PVDF membranes are suitable for aqueous samples, biological solutions, and protein sample filtration. Their low protein binding properties help reduce non-specific interactions between samples and the membrane material, making them ideal for filtering protein solutions, enzyme solutions, buffers, culture media, cell supernatants, and laboratory aqueous solutions. The 0.22 μm or smaller pore sizes are commonly used for liquid sterilization filtration, while 0.45 μm or larger pore sizes are suitable for retaining larger microorganisms, particle monitoring, and clarification filtration.
Durapore™ hydrophobic PVDF membranes are suitable for air sterilization, gas sterilization, solvent filtration, venting protection, aeration filtration, and hydrophobic barrier applications. Representative GVHP 0.22 μm hydrophobic PVDF product pages explicitly list Air sterilization, Gas sterilization, and Solvent filtration as key applications. Water flow rate parameters are measured under methanol pre-wetting conditions, making direct aqueous sample filtration less convenient compared to the hydrophilic version.
| Application Requirement | Recommended Type | Recommended Pore Size | Selection Rationale |
|---|---|---|---|
| Protein sample filtration | Hydrophilic PVDF | 0.22 μm / 0.45 μm | Low protein binding reduces sample loss and improves recovery |
| Bioburden reduction filtration of biological solutions | Hydrophilic PVDF | 0.22 μm or smaller | Suitable for liquid sterilization filtration; commonly used to remove bacteria, molds, and yeasts |
| Routine aqueous solution clarification | Hydrophilic PVDF | 0.45 μm | Faster flow rate, suitable for routine particle removal |
| High-particle-load sample pre-filtration | Hydrophilic PVDF | 0.65 μm / 5.0 μm | Larger pores provide higher flow rates, reducing clogging risk for subsequent fine filtration |
| Air/gas sterilization | Hydrophobic PVDF | 0.22 μm | Hydrophobic membrane allows gas passage and serves as an air/gas sterilization barrier |
| Organic solvent filtration | Hydrophobic PVDF | 0.22 μm / 0.45 μm | Suitable for non-aqueous systems and solvent filtration scenarios |
| Venting protection / aeration filtration | Hydrophobic PVDF | 0.22 μm / 0.45 μm | Hydrophobicity prevents aqueous liquid entry while allowing gas exchange |
| Microorganism retention and culture | Hydrophilic PVDF | 0.45 μm or larger | Suitable for retaining larger biological contaminants and supporting subsequent culture analysis |
Select pore size based on experimental objectives: 0.22 μm or smaller for sterilization filtration, 0.45 μm for routine clarification, and 0.65 μm or 5.0 μm for pre-filtration of turbid samples.
Place the membrane flat into the filter holder, ensuring it is free from creases, contamination, and damage.
Pre-wet the membrane with a small volume of the sample solution or a compatible buffer to eliminate air bubbles from the membrane surface.
Add the sample and begin filtration using vacuum filtration, positive pressure, syringe filtration, or a filter holder setup.
After filtration, collect the filtrate or retain the membrane-retained material based on the experimental objective.
For microbiological or biological sample processing, verify whether the membrane is sterile or requires sterilization prior to use according to protocol requirements.
For gas, air, venting protection, and organic solvent filtration, hydrophobic Durapore™ PVDF is the preferred choice.
Direct aqueous sample filtration with hydrophobic membranes is not recommended as a first choice. If hydrophobic membranes must be used for aqueous systems, pre-wet with a compatible solvent such as methanol or ethanol first, then rinse with water or buffer.
For gas filtration, confirm gas flow direction, filtration area, pressure range, and seal integrity.
Before solvent filtration, verify the material compatibility of the entire system, including the membrane, housing, gaskets, connectors, and filter apparatus.
After use, dispose of used membranes according to sample properties and laboratory safety regulations to avoid secondary contamination from residual organic solvents, biological contaminants, or hazardous chemicals.
| Precautions | Description |
|---|---|
| Do not interchange hydrophilic/hydrophobic | For aqueous samples, prioritize hydrophilic PVDF; for gas/solvent/venting applications, prioritize hydrophobic PVDF |
| Prioritize hydrophilic for protein samples | Hydrophilic Durapore™ PVDF has low protein binding (typical specification: 4 μg/cm² per performance data) |
| Hydrophobic type requires pre-wetting for aqueous samples | Hydrophobic PVDF is not easily wetted by water; water flow rates are typically measured after methanol pre-wetting |
| Control pressure and flow rate | Excessive pressure may cause membrane deformation, rupture, or reduced retention efficiency |
| Pre-filter turbid samples | High-particle samples filtered directly through 0.22 μm are prone to clogging; pre-treatment with larger pore size membranes is recommended |
| Verify sterilization method | Durapore™ general specifications support autoclaving, EtO, or gamma sterilization; however, specific products must be verified by catalog number |
| Verify full-system compatibility | PVDF membranes offer good compatibility, but filter funnels, holders, gaskets, and connectors must also be compatible with the sample |
| Confirm non-sterile packaging | Many disc membranes are supplied non-sterile; for sterile applications, confirm the sterilization process |
Q1: What is the main difference between Durapore™ hydrophilic and hydrophobic PVDF membranes?
A: Hydrophilic membranes are suitable for aqueous samples, biological solutions, and protein sample filtration; hydrophobic membranes are suitable for air, gas, solvents, venting protection, and aeration filtration.
Q2: Which membrane should I choose for protein solution filtration?
A: Durapore™ hydrophilic PVDF is recommended. Its low protein binding helps minimize sample loss and is suitable for experiments requiring maximum recovery.
Q3: Which membrane should I choose for air or gas filtration?
A: Durapore™ hydrophobic PVDF is recommended, with 0.22 μm or 0.45 μm commonly used for air sterilization, gas sterilization, and venting protection.
Q4: How do I choose between 0.22 μm and 0.45 μm?
A: 0.22 μm is better suited for sterile-grade filtration and higher retention requirements; 0.45 μm is better for routine clarification, microorganism retention, and particle monitoring, typically offering faster flow rates.
Q5: Can hydrophobic PVDF be used for aqueous solutions?
A: It can be used after pre-wetting, but it is not recommended as the first choice for aqueous samples. For aqueous solutions, buffers, or biological solutions, hydrophilic PVDF is generally more convenient.
Q6: What is the difference between Durapore™ PVDF and PTFE membranes?
A: PVDF is particularly well-suited for low protein binding and biological sample filtration; PTFE generally offers stronger chemical inertness and is often used for aggressive solvents, strong acids/bases, or specialized chemical systems. Aqueous protein samples are generally best handled with hydrophilic PVDF.
Q7: Can Durapore™ PVDF be used for sterilization filtration?
A: Yes. Hydrophilic Durapore™ PVDF with 0.22 μm or smaller pore sizes can be used for liquid sterilization filtration; hydrophobic 0.22 μm versions are commonly used for air or gas sterilization. Conformance to specific process requirements should be verified against the sample matrix, validation conditions, and corresponding catalog documentation.
Q8: Is Durapore™ PVDF low in extractables?
A: Yes. Manufacturer documentation describes Durapore™ as a low-extractable membrane, with general specifications listing weight extractables as<0.5%, making it suitable for experiments where filter leachables are a concern.
The core advantages of Millipore Durapore™ PVDF membranes are high flow rates, high throughput, low extractables, broad chemical compatibility, and low protein binding. For aqueous samples, biological solutions, protein samples, and liquid sterilization filtration, Durapore™ hydrophilic PVDF is recommended. For air sterilization, gas filtration, solvent filtration, venting protection, and hydrophobic barrier applications, Durapore™ hydrophobic PVDF is recommended. When making a final selection, consider sample properties, pore size, filtration area, flow rate, protein binding, sterilization methods, and overall filtration device compatibility.
📧 Email: contact@scimaterials.cn
📞 WhatsApp & Tel: +86 153-7569-8751
🔗 Place quick orders on our eBay / Amazon / Alibaba stores.
🌐 We ship worldwide via DHL, FedEx, UPS, SF-Express, or other requested carriers.
📦 Bulk quantities with discount available upon request.
💳 Payment methods accepted: Bank Wire Transfer, PayPal, Credit Card (via Taobao), Alipay, WeChat Pay
| Product Name | 0.1μm (VVLP) | 0.22μm (GVWP) | 0.22μm (CCGL, Charged) | 0.45μm (HVLP) | 0.45μm (HVWG) | 0.65μm (DVPP) | 5.0μm (SVLP) | 5.0μm (SVWG) |
|---|---|---|---|---|---|---|---|---|
| Millipore Durapore Hydrophilic PVDF Membrane, 30cm × 3m, 1 roll/pk | VVLP00010 $784 | GVWP00010 $1,749 | — | HVLP00010 $1,753 | — | DVPP00010 $825 | — | — |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ13mm, 100/pk | VVLP01300 $266 | GVWP01300 $266 | — | HVLP01300 $266 | — | DVPP01300 $266 | SVLP01300 $266 | — |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ25mm, 100/pk | VVLP02500 $323 | GVWP02500 $323 | — | HVLP02500 $323 | — | DVPP02500 $323 | SVLP02500 $323 | — |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ47mm, 100/pk | VVLP04700 $413 | GVWP04700 $413 | — | HVLP04700 $413 | HVWG04700 $486 | DVPP04700 $413 | SVLP04700 $447 | SVWG04700 $533 |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ90mm, 50/pk | VVLP09050 $556 | GVWP09050 $556 | — | HVLP09050 $556 | — | DVPP09050 $556 | SVLP09050 $757 | — |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ90mm, 25/pk | — | — | CCGL09025 $926 | — | — | — | — | — |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ142mm, 50/pk | VVLP14250 $985 | GVWP14250 $985 | — | HVLP14250 $985 | — | DVPP14250 $985 | — | — |
| Millipore Durapore Hydrophilic PVDF Membrane, Φ293mm, 25/pk | — | — | — | — | — | DVPP29325 $1,747 | — | — |
