Research-Grade Layered Ceramic Materials | Nominal Purity ≥99% | Multiple Elemental Systems | 200–500 Mesh Options
M₂AX Layered Structure Research-Grade Powder 13 Product Models Custom Specifications AvailableThe general structural formula of a ternary MAX phase (211) is M₂AX, where M is typically a transition metal, A is a main-group element, and X is carbon or nitrogen. Its crystal structure consists of alternating M–X layers and A-element layers, making it suitable for studies of phase structure, interlayer reactions, interfacial behavior, and two-dimensional derivative materials.
This series includes Mo₂GaC, Ta₂AlC, Cr₂AlC, Nb₂AlC, V₂AlC, V₂GeC, V₂GaC, V₂ZnC, V₂SnC, Mo₂GeC, Ti₂AlN, Ti₂AlC, and Ti₂SnC.
| Parameter | Product Information |
|---|---|
| Product Series | Ternary MAX Phase (211) |
| General Formula | M₂AX |
| Structure Type | 211-Type Layered MAX Phase |
| Product Form | Powder |
| Product Grade | Research Grade |
| Nominal Purity | ≥99% |
| Standard Mesh Sizes | 200, 300, 400, and 500 mesh, depending on the product model |
| Standard Packaging | 1 g, 5 g, 25 g, 50 g, and 250 g, depending on the product model |
| Characterization Data | Batch-specific XRD, SEM, EDS, and particle-size data are available upon request |
| Customization Services | Custom particle sizes, packaging, bulk quantities, and special parameters are available upon request |
| Product Feature | Description |
|---|---|
| Layered Crystal Structure | Alternating M–X layers and A-element layers support research on interlayer structures, interfaces, and two-dimensional materials |
| Multiple Elemental Systems | Covers combinations of Ti, V, Cr, Nb, Mo, and Ta with elements such as Al, Ga, Ge, Zn, and Sn |
| Research-Grade Purity | Nominal purity ≥99%, suitable for phase analysis, sintering, composite preparation, etching, and electrochemical experiments |
| Multiple Mesh Sizes | Available in 200–500 mesh to support sintering, dispersion, slurry preparation, coating, and composite applications |
| Flexible Packaging | Packaging options are available for preliminary trials, routine experiments, and larger-scale R&D |
| Customization Available | Special particle sizes, repackaging, bulk supply, and characterization requirements are available upon request |
| Product Model | Structure Type | M Element | A Element | X Element | Nominal Purity | Available Mesh Sizes | Standard Packaging | Recommended Research Areas |
|---|---|---|---|---|---|---|---|---|
| Mo₂GaC | 211 / M₂AX | Mo | Ga | C | ≥99% | 200, 300, 400, and 500 mesh | 1g/5g/50g | Interlayer structures, interfacial reactions, and two-dimensional derivative materials |
| Ta₂AlC | 211 / M₂AX | Ta | Al | C | ≥99% | 200, 300, 400, and 500 mesh | 1g/5g/50g | High-temperature ceramics, corrosion resistance, and structural-property studies |
| Cr₂AlC | 211 / M₂AX | Cr | Al | C | ≥99% | 200, 300, 400, and 500 mesh | 1g/5g/50g | Oxidation-resistant coatings, friction and wear, and ceramic-composite studies |
| Nb₂AlC | 211 / M₂AX | Nb | Al | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Energy storage, catalysis, conductive composites, and two-dimensional material precursors |
| V₂AlC | 211 / M₂AX | V | Al | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Energy storage, electrocatalysis, and MXene precursor studies |
| V₂GeC | 211 / M₂AX | V | Ge | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | A-layer reactions, electronic structure, and interfacial properties |
| V₂GaC | 211 / M₂AX | V | Ga | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Selective reactions, two-dimensional materials, and electrochemical studies |
| V₂ZnC | 211 / M₂AX | V | Zn | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Interlayer structures, A-layer chemistry, and two-dimensional materials |
| V₂SnC | 211 / M₂AX | V | Sn | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Thermal, electrochemical, and composite-material studies |
| Mo₂GeC | 211 / M₂AX | Mo | Ge | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Electronic structure, catalysis, and high-temperature performance |
| Ti₂AlN | 211 / M₂AX | Ti | Al | N | ≥99% | 200 and 400 mesh | 1g/5g/50g | Nitride MAX phases, high-temperature stability, and functional ceramics |
| Ti₂AlC | 211 / M₂AX | Ti | Al | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Sintered ceramics, coatings, composites, and interface studies |
| Ti₂SnC | 211 / M₂AX | Ti | Sn | C | ≥99% | 200 and 400 mesh | 1g/5g/50g | Thermal properties, interfaces, composites, and layered structures |
| Application Area | Application Description |
|---|---|
| Fundamental MAX Phase Research | Analysis of crystal structure, phase composition, defects, electronic structure, and interlayer interactions |
| MXene Precursors | Selected models can be used to selectively remove the A layer and prepare two-dimensional derivative materials |
| Electrochemical Energy Storage | Research on lithium-ion batteries, sodium-ion batteries, supercapacitors, and composite electrodes |
| Catalysis Research | Research on electrocatalysis, photocatalysis, thermocatalysis, and catalyst supports |
| High-Temperature Structural Materials | Research on high-temperature ceramics, thermal protection, and structural stability |
| Functional Coatings | Research on oxidation-resistant, wear-resistant, and protective coatings for metal or ceramic surfaces |
| Conductive Composites | Can be combined with metals, ceramics, polymers, graphene, and carbon nanomaterials |
| Friction and Lubrication | Research on wear-resistant materials, solid lubrication, and tribological performance |
| Electromagnetic Functional Materials | Research on electromagnetic shielding, microwave-absorbing materials, and conductive networks |
| Interface Engineering | Research on heterostructures, interlayer reactions, surface modification, and composite interfaces |
| Mesh Size | Powder Characteristics | Recommended Uses |
|---|---|---|
| 200 Mesh | Relatively coarse particles with good flowability | Solid-state reactions, sintering, pellet pressing, and composite preparation |
| 300 Mesh | Balances flowability and reaction activity | Routine mixing, preliminary formulations, and material screening |
| 400 Mesh | Finer powder with a relatively larger contact area | Slurries, coatings, dispersion, electrochemistry, and interfacial-reaction studies |
| 500 Mesh | Suitable for finer powder applications | Thin-layer coating, fine dispersion, and experiments requiring higher fineness |
| Procedure | Instructions |
|---|---|
| Product Selection | Select the product model according to the target elemental system, experimental temperature, composite matrix, and whether MXene preparation is intended |
| Opening and Sampling | Use clean, dry weighing tools to prevent cross-contamination between different materials |
| Powder Drying | For moisture-sensitive experiments, use low-temperature vacuum drying or drying under an inert atmosphere |
| Dispersion | Select a compatible solvent such as water, ethanol, or isopropanol, and disperse by stirring, ultrasonication, or ball milling as appropriate |
| Material Mixing | Mix uniformly with metals, ceramics, polymers, or other functional materials according to the experimental formulation |
| Forming and Sintering | Pellet pressing, hot pressing, or spark plasma sintering may be used. Temperature, pressure, and atmosphere should be optimized for the selected product model |
| Etching | When used as an MXene precursor, select the etching system according to the A-layer element and begin with a small-scale trial |
| Material Characterization | XRD, SEM, TEM, EDS, XPS, and particle-size analysis are recommended to verify the material condition |
| Experimental Requirement | Recommended Selection |
|---|---|
| Preliminary screening or phase characterization | Choose a 1 g or 5 g trial package |
| Routine composite, coating, or electrochemical experiments | Choose 5 g, 25 g, or 50 g packaging |
| Continuous experiments or larger-scale R&D | Choose 50 g or 250 g packaging |
| Solid-state reactions, pellet pressing, and sintering | Prefer 200 or 300 mesh |
| Slurry preparation, dispersion, and coating | Prefer 400 or 500 mesh |
| High-Temperature Oxidation-Resistance Research | Consider systems such as Cr₂AlC, Ta₂AlC, and Ti₂AlN |
| MXene Precursor Research | Select the corresponding MAX phase for the target two-dimensional material and verify etching feasibility in advance |
| Special A-Layer Element Research | Select products containing Ga, Ge, Zn, or Sn in the A layer |
| Item | Recommendation |
|---|---|
| Storage Environment | Store sealed in a cool, dry place away from light |
| Storage After Opening | Reseal promptly after use and avoid prolonged exposure to air |
| Long-Term Storage | Vacuum or inert-gas protection may be used according to experimental requirements |
| Personal Protective Equipment | Wear laboratory gloves, a particulate respirator, and safety goggles during handling |
| Dust Control | Avoid generating airborne dust. Work in a fume hood or an area equipped with appropriate dust-control measures |
| Waste Disposal | Dispose of the material in accordance with laboratory procedures for inorganic powders or chemical-material waste |
| Intended Use | For scientific research and industrial R&D only. Not intended for food, medical, or human-use applications |
Research-grade powders ' 200–500 mesh options ' 1 g, 5 g, and 50 g packages
| Product Model | Mesh Size | 1 g (USD) | 5 g (USD) | 50 g (USD) |
|---|---|---|---|---|
| Mo₂GaC | 200 Mesh | $50 | $225 | $1,913 |
| 300 Mesh | $52 | $233 | $1,976 | |
| 400 Mesh | $53 | $240 | $2,040 | |
| 500 Mesh | $55 | $248 | $2,104 | |
| Ta₂AlC | 200 Mesh | $10 | $45 | $383 |
| 300 Mesh | $11 | $48 | $408 | |
| 400 Mesh | $11 | $51 | $434 | |
| 500 Mesh | $12 | $54 | $459 | |
| Cr₂AlC | 200 Mesh | $10 | $45 | $383 |
| 300 Mesh | $11 | $48 | $408 | |
| 400 Mesh | $11 | $51 | $434 | |
| 500 Mesh | $12 | $54 | $459 | |
| Nb₂AlC | 200 Mesh | $24 | $108 | $453 |
| 400 Mesh | $27 | $123 | $495 | |
| V₂AlC | 200 Mesh | $24 | $108 | $453 |
| 400 Mesh | $27 | $123 | $495 | |
| V₂GeC | 200 Mesh | $53 | $238 | $1,083 |
| 400 Mesh | $58 | $261 | $1,188 | |
| V₂GaC | 200 Mesh | $53 | $238 | $1,083 |
| 400 Mesh | $58 | $261 | $1,188 | |
| V₂ZnC | 200 Mesh | $39 | $174 | $776 |
| 400 Mesh | $44 | $200 | $888 | |
| V₂SnC | 200 Mesh | $39 | $174 | $776 |
| 400 Mesh | $44 | $200 | $888 | |
| Mo₂GeC | 200 Mesh | $63 | $285 | $1,396 |
| 400 Mesh | $65 | $292 | $1,531 | |
| Ti₂AlN | 200 Mesh | $22 | $100 | $411 |
| 400 Mesh | $25 | $113 | $453 | |
| Ti₂AlC | 200 Mesh | $11 | $49 | $412 |
| 400 Mesh | $14 | $64 | $544 | |
| Ti₂SnC | 200 Mesh | $24 | $108 | $411 |
| 400 Mesh | $25 | $113 | $453 |
