A hydrophilic separator material designed for zinc–nickel batteries, metal-air batteries, and related alkaline electrochemical systems.
Available in multiple widths, thicknesses, and roll lengths, it is suitable for physical electrode isolation, electrolyte wetting retention, and ion transport-related research applications.
Type
Hydrophilic Battery Separator
Standard Thickness
32 / 40 μm
Standard Width Range
99–250 mm
Supply Format
Roll Material / Area Pack
Thin Film Roll Material · Hydrophilic Wetting · Battery Separation
Standard Commercial Thickness
Multiple Width Options
Standard Roll Length
Optional Area Pack
Based on a hydrophilic thin-film structure, the separator can be selected according to thickness, width, roll length, and surface characteristics.
Youveim® Zinc–Nickel Air Battery Hydrophilic Separator is mainly designed for battery and electrochemical research applications requiring hydrophilic wetting performance.
The separator is positioned between positive and negative electrodes to provide physical isolation while maintaining electrolyte transport pathways.
Standard roll thicknesses include 32 μm and 40 μm, with widths covering:
A 1 m² area pack format is also available for selected specifications.
Different battery structures may require different separator thicknesses, surface conditions, wetting properties, compression characteristics, and chemical stability.
For new electrolyte systems, validation testing is recommended before full application.
| Item | Specification |
|---|---|
| Product Type | Hydrophilic Battery Separator |
| Supply Format | Roll Material / 1 m² Area Pack |
| Standard Thickness | 32 / 40 μm |
| Width Range | 99–250 mm |
| Surface Condition | Standard / Special Dual-Surface Structure |
| Selection Variables | Width / Thickness / Length |
Designed for electrochemical research scenarios requiring rapid electrolyte contact and continuous wetting performance.
Commercial thickness options include 32 μm and 40 μm, suitable for compact battery structures.
Available widths from 99 mm to 250 mm, supporting different electrode sizes and experimental fixtures.
Multiple roll lengths and area-pack formats allow convenient laboratory cutting according to actual requirements.
Recommended selection sequence:
Thickness → Width → Required Length → Surface Condition
Available widths include:
99 / 110 / 202 / 210 / 250 mm
Current commercial specifications include:
99 mm and 250 mm widths.
Available in:
210 mm and 250 mm width area packs.
Selected specifications are available with special surface structures.
The following data is organized based on the provided parameter image.
The values are intended for material screening and technical communication only, and should not be considered guaranteed batch specifications for all commercial products.
Reference Sample Thickness: Approximately 40 μm Separator
Measured parameters include:
| Parameter | Unit | Test Method | Requirement | Average Value |
|---|---|---|---|---|
| Basis Weight | g/m² | / | 20.0 ± 5.0 | 23.5 |
| Thickness | μm | / | 40 ± 2 | 39 |
| Width | mm | / | 210 / 250 | 210 / 250 |
| Porosity | % | / | 37–38 | 42.4 |
| Air Permeability | s | Gurley, 100 mL | 500–1000 | 888 |
| Tensile Strength (MD) | MPa | GB 13022 | ≥100 | 124 |
| Tensile Strength (TD) | MPa | GB 13022 | ≥25 | 26.3 |
| Thermal Shrinkage (MD) | % | 90 ±2℃, 2 h | ≤2.0 | 0.72 |
| Thermal Shrinkage (TD) | % | 90 ±2℃, 2 h | ≤1.5 | 0.33 |
| Puncture Strength | N | / | ≥4.5 | 5.94 |
| Area Resistance | Ω·cm² | After soaking in 30% KOH for approx. 1.5 h | ≤0.2 | 0.066 |
The original reference image indicates:
These values show inconsistency and should be verified against the original inspection report before official publication.
The above physical property table represents an approximately 40 μm separator sample and should not be directly applied to the 32 μm commercial specification.
Only final selling prices are displayed.
Procurement costs are not shown.
| Width | Thickness | Length / Area | Description | Price |
|---|---|---|---|---|
| 99 mm | 32 μm | 10 m | Standard Hydrophilic Separator | $26 |
| 110 mm | 32 μm | 9 m | Standard Hydrophilic Separator | $26 |
| 202 mm | 32 μm | 5 m | Standard Hydrophilic Separator | $26 |
| 210 mm | 32 μm | 5 m | Standard Hydrophilic Separator | $26 |
| 250 mm | 32 μm | 4 m | Standard Hydrophilic Separator | $26 |
| 99 mm | 40 μm | 5 m | Standard Hydrophilic Separator | $26 |
| 250 mm | 40 μm | 4 m | Standard Hydrophilic Separator | $26 |
| 210 mm | — | 1 m² | Area Pack | $18 |
| 210 mm | — | 1 m² | One Smooth Side / One Rough Side | $22 |
| 250 mm | — | 1 m² | Area Pack | $18 |
Price unit: RMB / package
“—” indicates that thickness information was not specified in the original sales specification.
Please confirm complete specifications before purchase.
Used for electrode separation, electrolyte retention, and battery structure research.
Suitable for alkaline metal-air battery research involving separator wetting behavior and structural influence studies.
Supports comparative evaluation of:
Choose between:
according to battery space, electrode spacing, and compression conditions.
The separator should cover the required isolation area while maintaining appropriate edge allowance according to battery structure.
For new electrolyte systems, perform:
before application.
Use clean and sharp cutting tools.
Avoid:
Selection depends on:
For new structures, purchasing both thickness options for comparison testing is recommended.
No.
The provided reference data represents an approximately 40 μm separator sample and should be used only for material evaluation reference.
The original sales specification does not provide thickness information for certain area-pack products.
Please confirm the complete specification before purchase.
Yes.
The roll format allows laboratory users to cut according to specific experimental requirements.
Clean cutting tools are recommended.
The reference test includes resistance measurement after immersion in approximately 30% KOH electrolyte.
Actual compatibility should be verified according to the specific battery system.
Hydrophilic separator roll material designed for zinc–nickel batteries, metal-air batteries and alkaline electrochemical research. Multiple widths, thicknesses and roll lengths are available for laboratory battery structures and separator screening.
| Width | Thickness | Length / Area | Specification | Price |
|---|---|---|---|---|
| 99 mm | 32 μm | 10 m | Standard Hydrophilic Separator | $26 |
| 110 mm | 32 μm | 9 m | Standard Hydrophilic Separator | $26 |
| 202 mm | 32 μm | 5 m | Standard Hydrophilic Separator | $26 |
| 210 mm | 32 μm | 5 m | Standard Hydrophilic Separator | $26 |
| 250 mm | 32 μm | 4 m | Standard Hydrophilic Separator | $26 |
| 99 mm | 40 μm | 5 m | Standard Hydrophilic Separator | $26 |
| 250 mm | 40 μm | 4 m | Standard Hydrophilic Separator | $26 |
| 210 mm | - | 1 m² | Standard Sheet Format | $18 |
| 210 mm | - | 1 m² | One Smooth Side · One Rough Side | $22 |
| 250 mm | - | 1 m² | Standard Sheet Format | $18 |
